Multi-Function Tool
Set Up and Operating Instructions
Visit us at crlaurence.com for international toll free information
C.R. LAURENCE Co., INC.
CAT. NO. MFT1
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL
C ON TEN TS
Page 3.
Page 4.
Page 8.
Page 11. Assembly and Operation
Page 13. Maintenance
Page 14. Exploded View
Page 15. Spare Parts List
COPYRIGHT C.R. LAURENCE CO., INC. 2012
©
Introduction
Machine Information
Safety Instructions
AVDB3030_11/11
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CRL MFT1
Summary of Contents for CRL MFT1
- Page 1 C.R. LAURENCE Co., INC. Multi-Function Tool Set Up and Operating Instructions CAT. NO. MFT1 Read this material before using this product. Failure to do so can result in serious injury. SAVE THIS MANUAL C ON TEN TS Page 3. Introduction Page 4.
- Page 2 C.R. LAURENCE CO., INC. MA C H IN E IN FOR M ATION Fig. 1 Features Fig. 1 1. On/Off Switch 2. Speed Control 3. Sanding Pad 4. Sanding Paper 5. E-Cut Saw Blade 6. Scraper 7. Carbide Blade 8. HSS Saw Blade 9.
- Page 3 Contents 1. Machine Data 2. Safety Instructions 3. Assembly and Operation 4. Maintenance MA C H IN E IN FOR M ATION Technical Specification MFT1 Package Contents Voltage 110 V~ Frequency 60 Hz Power Input 2.2 A...
-
Page 4: Safety Instructions
C.R. LAURENCE CO., INC. SA FETY IN STR U C TION S The following pictograms are used in these instructions: Denotes risk of personal injury, loss of life or damage to the tool in case of non-observance of the instructions in this manual. Indicates electrical shock hazard. - Page 5 C.R. LAURENCE CO., INC. 3) Personal Safety a. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication.
-
Page 6: Voltage
C.R. LAURENCE CO., INC. h. Damaged switches must be replaced. Do not use power tools that cannot be switched on and off. i. Do not leave power tools unattended while they are switched on. Always switch off the tool and wait until it has come to a full standstill before leaving. j. -
Page 7: Visit Us At Crlaurence.com For International Toll Free Information
C.R. LAURENCE CO., INC. Replacing cable or plugs If the electrical cable becomes damaged, it must be replaced with a special electrical cable available from the manufacturer or the manufacturer's customer service. Dispose of old cables or plugs immediately after replacing them with new ones. It is dangerous to connect the plug of a loose cable to a socket. -
Page 8: Maintenance
C.R. LAURENCE CO., INC. Mounting accessories For saw blades, scrapers, and disc cutters and cutting discs use the clamping screw in combination with the retaining ring. • Remove the clamping screw using an Allen key. • Replace the tool and tighten it using the clamping screw. Check that the tool is secure in the chuck and that the machine is correctly secured and supported. -
Page 9: Visit Us At Crlaurence.com For International Toll Free Information
C.R. LAURENCE CO., INC. EXPLOD ED VIEW 28 29 (41) Visit us at crlaurence.com for international toll free information... -
Page 10: Visit Us At Crlaurence.com For International Toll Free Information
C.R. LAURENCE CO., INC. SPA R E PA R TS LIST PARTS NAME PARTS NAME screw spring output shaft dust ring switch knob check ring small switch knob wave washer pull rod bearing brush holder swing preset spring axle preset brush screw screw...
