  • Page 1 EZiSYSTEM including xf-Series User Manual Version 1.1 English...
  • Page 2 EZiSYSTEM, Introduction Introduction Purchase Congratulations on your purchase of an EZiSYSTEM instrument. This manual contains important safety directions as well as instructions for setting up the product and operating it. Refer to "9 Safety Directions" for further information. Read carefully through the User Manual before you switch on the product. Product identification The model and the serial number of your product are indicated on the type plate.
  • Page 3 Symbols The symbols used in this manual have the following meanings: Type Description Danger Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. Warning Indicates a potentially hazardous situation or an unintended use which, if not avoided, could result in death or serious injury.

  • Page 4: Table Of Contents

    EZiSYSTEM, Table of Contents Table of Contents In this manual Chapter Page General Information How to Use this Manual i-Series General Information i-Series Instruments and Accessories How to Use the Locator General Information Locator Overview Locator Setup and Information Hazard Zone How to Locate a Service Wireless Data Communication, where applicable Memory &...
  • Page 5 How to Use the Signal Clamp General Information Signal Clamp Overview How to Locate a Service Using the Signal Clamp How to Use the Property Connection Set General Information Property Connection Set Overview How to Locate a Service Using the Property Connection Set How to Use the Sonde General Information Sonde Overview...
  • Page 6 EZiSYSTEM, Table of Contents Technical Data 10.1 Locator i-Series Technical Data 10.2 Transmitter Technical Data (1 Watt models) 10.3 Conductive Rod Technical Data 10.4 Sonde Technical Data 10.5 Maxi Sonde Technical Data 10.6 Property Connection Set Technical Data 10.7 Signal Clamp Technical Data 10.8 Multi Clamp Technical Data International Limited Warranty...

  • Page 7: General Information

    General Information How to Use this Manual  It is recommended to set up the product while reading through this manual. Naming convention EZiCAT i500, i550, i600, i650, i700, i750 and xf models are hereinafter referred to as Locator. Differences between the models are marked and described. EZiTEX t100, t300 and xf models is hereinafter referred to as Transmitter.

  • Page 8: I-Series General Information

    EZiSYSTEM, General Information i-Series General Information Description Locators are used to detect buried conductive services emitting an electromagnetic signal which is generated by a current passing through the service. Transmitters are used to apply a distinct signal to conductive services, which may not radiate electromagnetic signals or may need to be traced for a specific purpose.
  • Page 9 Accessories Designed to increase the detection of services with no (or little) signals on them. Generally work in conjunction with the Locator and Transmitter. Functional Check Designed to demonstrate the equipment is working satisfactorily in between service inter- vals. Refer to "Appendix A Functional Checks" for more information. EZiSYSTEM, General Information...

  • Page 10: I-Series Instruments And Accessories

    EZiSYSTEM, General Information i-Series Instruments and Accessories General information The i-Series is a collection of products used to locate buried metallic and nonmetallic services. i-Series instruments overview a) Locator b) Transmitter i-Series accessories overview a) Conductive Rod (non metallic service tracer) b) Extension Cable c) Property Connection d) Signal Clamp...

  • Page 11: How To Use The Locator

    How to Use the Locator General Information Operating modes • Passive modes: Power and Radio • Active modes: 8 kHz, 33 kHz, additionally 512 Hz and 640 Hz on xf models • Auto mode: Combined Power and Radio modes Electromagnetic signals An electromagnetic signal radiates from buried conductive services as an electrical current flows through them.
  • Page 12 EZiSYSTEM, How to Use the Locator Hazard zone Provides an additional alarm, indicating the close proximity of a service emitting a Power, 8 kHz, 33 kHz (512 Hz and 640 Hz on xf models) signal. Peak hold Assists in pinpointing a service by displaying the peak reading for a short period of time.

  • Page 13: Locator Overview

    Locator Overview Locator main parts a) Display Panel Contains the operational controls. b) Speakers (mounted internally left and right) Active at power on and when a signal is detected. c) On/Off Trigger Press and hold the trigger to activate the Locator. Release the trigger to deactivate.
  • Page 14 EZiSYSTEM, How to Use the Locator Display panel overview a) Signal Strength Indicator Indicates the response of the Locator to a signal (service). b) Mode Indicators Displays the selected mode: Power, Radio, 8 kHz, (512 Hz and 640 Hz on xf models). 33 kHz, Auto, s shown, from bottom to top.
  • Page 15 i) Numeric Signal Strength Indicator (SSI) Symbol Static: SSI is enabled No Symbol: SSI is disabled j) Current Indicator (i550xf, i650xf and i750xf) Indicates the amount current flowing through a service which is applied by the Transmitter. This is measured in milliamperes (mA). k) Measurement Unit (Depth indication with the i550, i650, i550xf, i650xf and i750xf) Indicates depth indication is in metric or feet and inches.

  • Page 16: Locator Setup And Information

    EZiSYSTEM, How to Use the Locator Locator Setup and Information Locator settings The i-Series Locators offer a range of settings which the operator can adjust to their own preference. It also displays additional service and contact information as detailed. Setting Description Performs a function check on the locators hardware and software, displaying PAS if the Locator is within predefined tolerance or...
  • Page 17 Setting Description Displays the last stored log number 001 to 999. (i600, i650, i700, i750, i600xf, i650xf, i750xf) Adjusts the Bluetooth output options. (i600, i650, i600xf & i650xf) Setting COM Adjusts the locators Bluetooth or GPS settings: (i700, i750 & i750xf) PC: Enables Bluetooth communication to Logicat Software BT1: Enables Bluetooth option 1 (refer to section 2.6) BT2: Enables Bluetooth option 2 (refer to section 2.6)
  • Page 18 EZiSYSTEM, How to Use the Locator Danger The Locator may fail to detect electrical services in Power mode if an incorrect power setting is used. Precautions: Before use, verify the Locator is setup to be compatible with mains frequency supply in your country.

  • Page 19: Hazard Zone

    Hazard Zone Description Provides an additional warning to the close proximity of buried services and functions in the following modes: • Power • 8 kHz • 33 kHz • Auto mode (Power mode only) • 512 Hz & 640 Hz (xf models only) Hazard zone Status indicator Description...
  • Page 20 EZiSYSTEM, How to Use the Locator Caution The absence of a positive indication does not guarantee the non-existence of a service. Services without a detectable signal may be present. The Locators can only locate non-metallic services such as plastic pipes, typically used by the water and gas utilities, with the use of appropriate accessories.

  • Page 21: How To Locate A Service

    How to Locate a Service Start up test The following test sequence will take place every time the Locator is activated. On test Test pattern Info on label Audio Output On throughout test sequence Signal Strength indi- Scrolls through in cator sequence once Mode indicators...
  • Page 22 EZiSYSTEM, How to Use the Locator Locating process The locating process is split into three steps: • Sweep Search • Pinpointing the service • Direction of the service  Sweep Search Auto mode combines the benefit of simultaneous detection in Power and Radio modes and helps to confirm the presence of services upon initial site...
  • Page 23 3. Repeat the Sweep Search process in Radio mode.  The Sweep Search must be conducted in Power and Radio modes as a minimum, as not all services (including some electrical ones) emit a power signal. These services may be found using Radio mode or active modes. ...
  • Page 24 EZiSYSTEM, How to Use the Locator Peak hold When activated peak hold will show the highest peak reading obtained during the pinpoint process. The displayed reading can be adjusted between 0 to 5 seconds. Detecting direction of the 1. Position the Locator directly service over the service.
  • Page 25 Depth Indication 1. Apply a signal to the service. (i550, i650, i750, i550xf, Refer to "3 How to Use the i650xf and i750xf) Transmitter" for more informa- tion. 2. Select the mode to suit the Transmitter’s output. Position the Locator directly over, and at 90 degrees to the direction of the service.
  • Page 26 EZiSYSTEM, How to Use the Locator Depth shown and actual depth: d1 Depth shown on the EZiCAT = depth to the centre of the line. d2 Actual depth of the service. Note the difference between d1 and d2!
  • Page 27 Warning The depth reading might not reflect the real depth if your Locator picks up the signal induced into the service by the Transmitter. This signal is radiated from the centre of the service. This is even more important when the signal is produced by a Sonde, lying in a large diam- eter conduit! Precautions: Always compensate depth reading for service size.
  • Page 28 EZiSYSTEM, How to Use the Locator  • Activating line depth will provide an inaccurate readout. • Mark utilities with marker paint, pegs, flags or similar. Never drive pegs into the ground over the service. • Additional services may be within the excavation zone, as well as the service you are taking a depth reading from.
  • Page 29 Depth code information Information code Description Information on instru- ment label The service is too shallow to register prop- metres ft-inch erly. metres ft-inch 0.3 m The service is too deep. metres ft-inch metres ft-inch 3.0 m 10ft The signal received by the Locator is too small to register properly.
  • Page 30 EZiSYSTEM, How to Use the Locator Information code Description Information on instru- ment label The signal received by the Locator is too large to register properly. Depth function not available. The Locator is set to the wrong mode for a depth reading to be taken.
  • Page 31 Current Measurement Current Measurement is used to identify the service to which the transmitter is attached, (i550xf, i650xf and i750xf) this is measured in milliamperes (mA). The transmitter is used to apply a signal (current) to the required service. The signal can also couple to additional services making it hard to distinguish by conventional locating techniques.
  • Page 32 EZiSYSTEM, How to Use the Locator The signal (current) applied by the transmitter decreases at a uniform rate as it travels along the service. This can help to identify the service layout, as connections off it have a corresponding reduction in current. A sudden reduction in current may indicate damage to the service.
  • Page 33 Taking a Current Measurement 1. Apply a signal to the service. Refer to "3 How to Use the Transmitter" for more informa- tion. 2. Select the mode to suit the transmitters output. Position the Locator directly over, and at 90 degrees to the direction of the service.

  • Page 34: Wireless Data Communication, Where Applicable

    EZiSYSTEM, How to Use the Locator Wireless Data Communication, where applicable Bluetooth Bluetooth status is indicated on the locators display, the Bluetooth symbol will be illumi- nated when Bluetooth connectivity is available. Data can be wirelessly transferred from a Bluetooth enabled Locator to a suitable data logging device, enabling the operator to capture information about the Locator’s status and the service depth.
  • Page 35 ASCII text description ASCII output pattern: • BT1 (standard on all Bluetooth enabled locators): DVxxxSNxxxxxxSVxxxxTMxxxxxDTdd/mm/yyCMxxSTxBTxMDxSSxxUMxDPxxxx • BT2 (model dependent): DPxxxxUMxMDxSSxxDVxxxSNxxxxxxCMxxBTxSTxSVxxxxDTxxxxxxxxTMxxxxx EZiSYSTEM, How to Use the Locator...
  • Page 36 EZiSYSTEM, How to Use the Locator Data output Range Example value Description 000 to 999 Model identifier 000000 to 999999 123456 Serial number 0.00 to 9.99 3.01 Software version 00:00 to 23:59 08:30 Time: hh:mm (default = 00:00; no RTC fitted) 00/00/00 to 31/12/99 01/12/10 Date: dd/mm/yy (default = 00/00/00;...

  • Page 37: Memory & Communication

    Memory & Communication Data Records The i600, i650, i700, i750, i600xf, i650xf and i750xf locators record and store information whilst they are in use. The locators start to record information every second after comple- tion of the initial start-up routine. These records (logs) are stored in the locator’s memory and can be retrieved and transferred via Bluetooth to a PC for analysis.

  • Page 38: Internal Gps

    EZiSYSTEM, How to Use the Locator Internal GPS Data Records The i700, i750, i750xf locators have an internal GPS module which is used to record the geographical position of use. The geographical position (Latitude and Longitude) is stored in the log file and provides information on where the locator was used. The M icon is used to display the GPS status as follows: M flashing: GPS fix available and the geographical position is being recorded to the loca- tors log files.
  • Page 39  GPS Search Mode (i700, i750 & i750xf) A GPS search mode is activated as part of the start up test allowing the internal GPS module time to search for a GPS position. GPS search mode is active following the start up test even if the locator is off, the search mode will stop when a GPS position is obtained or a 12 minute search period has elapsed.

  • Page 40: How To Use The Transmitter

    EZiSYSTEM, How to Use the Transmitter How to Use the Transmitter General information Tracing signal The Transmitter applies an electrical current (signal) onto a buried metallic service, which enables the service to be traced and identified by the Locator operating in the same mode. Operating mode There are three operating modes for onsite flexibility: •...
  • Page 41 Description Active tracing is a term frequently used when a Transmitter is used to apply a signal to a service enabling it to be traced. The use of a Transmitter will greatly improve the detection of services especially ones which may not have a signal on them. The signal from the Transmitter can be applied to services in two ways: •...

  • Page 42: Transmitter Overview

    EZiSYSTEM, How to Use the Transmitter Transmitter Overview Transmitter main parts a) Battery Cover b) Accessory Compartment c) Connection Socket Used to connect accessories directly to metallic services. (Standard: crocodile clip cable set.) d) Speaker e) Power Output Control and Indicator Press the control to set the Transmitters power output.
  • Page 43 Changing the battery The battery indicator flashes to indicate a poor battery condition. 1. Unscrew the fastener and open the cover. 2. Replace all batteries with four new LR20 (D) type alkaline batteries, or remove and recharge the battery pack if rechargeable batteries are fitted.
  • Page 44 EZiSYSTEM, How to Use the Transmitter Warning Risk of electric shock when removing the Transmitter's battery pack. Precautions: Before removing the battery pack switch the transmitter off and remove any cable set or accessories from the connection socket. Caution The Transmitter's battery pack may get hot after prolonged use. Precautions: Allow the battery pack to cool down before removing.

  • Page 45: How To Locate A Service Using The Transmitter

    How to Locate a Service Using the Transmitter Start up test The following test sequence will take place every time the Transmitter is activated. On test Test pattern Audio output On throughout test sequence. LEDs LEDs are all lit throughout the test sequence. Default mode selection 33 kHz and power output level two is automatically selected.
  • Page 46 EZiSYSTEM, How to Use the Transmitter Using the Transmitter in Induction mode 1. Switch the Transmitter on, observe the Induction mode LED is illuminated and the battery level is adequate. Change batteries when indicated. Select the required power output level and frequency output. 2.
  • Page 47 Using the Transmitter in Connection mode 1. Plug the Transmitter’s cable set into the connection socket. 2. Connect the black cable to the Earth Pin, ensuring that no services are below push the Earth Pin into the ground. 3. Connect the red cable to the service. 4.
  • Page 48 EZiSYSTEM, How to Use the Transmitter Danger Connecting the cable set to a live service can result in an electric shock. Precautions: The connection cable set should never be connected directly to a live service. Warning The transmitter is capable of outputting potentially lethal voltages. Precautions: Care should be taken when handling exposed or non-insulated connections including;...

  • Page 49: How To Use The Conductive Rod

    How to Use the Conductive Rod General Information Description The Conductive Rod is a service tracer enabling small diameter non-conductive pipes or ducts to be traced. It can be used in Line mode or Sonde mode. Conductive Rod Overview Conductive Rod main parts a) End of Coil: Sonde mode Used to accurately pinpoint the end...

  • Page 50: How To Locate A Service Using The Conductive Rod

    EZiSYSTEM, How to Use the Conductive Rod How to Locate a Service Using the Conductive Rod Using the Conductive 1. Insert the rod into the pipe, duct, Rod in Line mode conduit or drain until the desired length is in place. 2.
  • Page 51  • Ensure there are no services below the ground when using the Earth Pin. Use the Locator in advance. • At least half the Conductive Rod needs to be uncoiled when in use. Using the Conductive 1. Insert the rod into the pipe, duct, conduit or drain until the desired length is in place. Rod in Sonde mode 2.

  • Page 52: How To Use The Signal Clamp

    EZiSYSTEM, How to Use the Signal Clamp How to Use the Signal Clamp General Information Description The Signal Clamp provides a safe technique of applying a signal to services such as telecom cables, etc. It is connected to the Transmitter and then clipped around the service. Supply is not interrupted by the applied signal.

  • Page 53: How To Locate A Service Using The Signal Clamp

    How to Locate a Service Using the Signal Clamp Using the Signal Clamp 1. Connect the Signal Clamp to the Transmitter. 2. Open the jaws of the Signal Clamp and place around the service to be traced. 3. Switch the Transmitter on and select the required power output level, set the frequency output to correspond with the clamp.
  • Page 54 EZiSYSTEM, How to Use the Signal Clamp Danger A hazardous signal may be present on the service causing personal harm. Precautions: Do not use on electrical services which have impaired, or no insulation. If in doubt do not use.

  • Page 55: How To Use The Property Connection Set

    How to Use the Property Connection Set General Information Description The Property Connection Set provides a safe technique of applying a traceable signal to live electricity cables. It is connected to the service via a mains plug outlet and provides a trace- able signal.

  • Page 56: How To Locate A Service Using The Property Connection Set

    EZiSYSTEM, How to Use the Property Connection Set How to Locate a Service Using the Property Connection Set Using the Property Connection Set 1. Connect the Property Connection Set to the Transmitter. 2. Connect the Property Connection Set to a live mains outlet. Ensure the switch on the mains is on.
  • Page 57 Danger A hazardous signal may be present on the connection plug of the Property Connection Set when connected to the mains supply. Precautions: The Property Connection Set should be connected to the Transmitter before connecting to the mains supply. Danger When using a Property Connection Set a hazardous signal may be present on the service or mains outlet causing personal harm.

  • Page 58: How To Use The Sonde

    EZiSYSTEM, How to Use the Sonde How to Use the Sonde General Information Description The Sonde is a signal transmitter used to trace drains, sewers and other non conductive services. It can be attached to a range of equipment including drain rods, boring tools and inspection cameras.
  • Page 59 Changing the frequency Changing to 33 kHz mode: output 1. Unscrew and remove end cap. Insert battery, positive end first. Refit end cap securely. 2. Hold Sonde upright. Confirm green LED is continuous. 3. Wait approximately 10 seconds for the green LED to start flashing.
  • Page 60 EZiSYSTEM, How to Use the Sonde Changing to 8 kHz mode: 1. Unscrew and remove end cap. Insert battery, positive end first. Refit end cap securely. 2. Hold Sonde upright. Confirm green light is continuous. 3. Rotate Sonde so the LED points down and wait approxi- mately 1 second.

  • Page 61: Maxi Sonde Overview

    Maxi Sonde Overview Maxi Sonde main parts a) Maxi Sonde body b) LED c) 3x LR6 (AA) battery d) End cap and M10 connection point  The thread on the Maxi Sonde is a male M10, and comes with adaptors to both British and European drain rods.
  • Page 62 EZiSYSTEM, How to Use the Sonde Changing the frequency Changing to 33 kHz mode: output 1. Unscrew and remove end cap. 2. Insert the batteries, positive end first. 3. Refit end cap securely. With the green LED flashing, the Sonde is ready for use at 33 kHz.
  • Page 63 Changing to 8 kHz mode: 1. Unscrew and remove end cap. 2. Insert the batteries, positive end last. 3. Refit end cap securely. With the amber LED flashing, the Sonde is ready for use at 8 kHz. LEDs indicating battery If the amber and green LEDs are condition flashing you need to replace the...

  • Page 64: How To Locate A Service Using The Sonde

    EZiSYSTEM, How to Use the Sonde How to Locate a Service Using the Sonde Attaching the Sonde to a Once the function of the Sonde has been checked with a Locator set to the same operating drain rod mode it can be attached to drain rods or other means of guiding it into the service being traced.
  • Page 65 3. Depth indication (refer to Sonde Depth in How to Use the Locator section) Depth indication can be used with a suitable depth locator. The locator must be posi- tioned directly over the Sonde and in line with it (rotate the locator on its axis to find the highest reading).

  • Page 66: Care And Transport

    EZiSYSTEM, Care and Transport Care and Transport Transport Transport in the field When transporting the equipment in the field, always make sure that you carry the product in its original transport container. Transport in a road Never carry the product loose in a road vehicle, as it can be affected by shock and vibration. vehicle Always carry the product in its transport container and secure it.

  • Page 67: Cleaning And Drying

    Cleaning and Drying Damp products Dry the product, the transport container, the foam inserts and the accessories at a temper- ature not greater than 40°C / 104°F and clean them. Do not repack until everything is completely dry. Cables and plugs Keep plugs clean and dry.

  • Page 68: Safety Directions

    EZiSYSTEM, Safety Directions Safety Directions General Introduction Description The following directions should enable the person responsible for the product, and the person who actually uses the equipment, to anticipate and avoid operational hazards. The person responsible for the product must ensure that all users understand these direc- tions and adhere to them.

  • Page 69: Limits Of Use

    • Use of products with obviously recognizable damages or defects. • Use with accessories from other manufacturers without the prior explicit approval of Cable Detection. • Inadequate safeguards at the surveying site, for example when measuring on roads. Warning Adverse use can lead to injury, malfunction and damage. It is the task of the person respon- sible for the equipment to inform the user about hazards and how to counteract them.

  • Page 70: Hazards Of Use

    EZiSYSTEM, Safety Directions Person in charge of the The person in charge of the product has the following duties: product • To understand the safety instructions on the product and the instructions in the user manual. • To ensure that it is used in accordance with the instructions. •...
  • Page 71 Danger Because of the risk of electrocution, it is very dangerous to use the product in the vicinity of electrical installations such as power cables or electrical railways. Precautions: Keep at a safe distance from electrical installations. If it is essential to work in this environ- ment, first contact the safety authorities responsible for the electrical installations and follow their instructions.
  • Page 72 EZiSYSTEM, Safety Directions Danger The Locator may fail to detect electrical services in Power mode if an incorrect power setting is used. Precautions: Before use, verify the Locator is setup to be compatible with mains frequency supply in your country. Options are 50 or 60 Hz. Refer to "Appendix B World Frequency Zones" (User Manual) for more information.
  • Page 73 Danger When using a Property Connection Set a hazardous signal may be present on the service or mains outlet causing personal harm. Precautions: Do not use on electrical services which have impaired, or no insulation. If in doubt do not use.
  • Page 74 EZiSYSTEM, Safety Directions Warning Risk of electric shock when removing the Transmitter's battery pack. Precautions: Before removing the battery pack switch the transmitter off and remove any cable set or accessories from the connection socket. Caution The Transmitter's battery pack may get hot after prolonged use. Precautions: Allow the battery pack to cool down before removing.

  • Page 75: Electromagnetic Compatibility Emc

    Caution During the transport, shipping or disposal of batteries it is possible for inappropriate mechanical influences to constitute a fire hazard. Precautions: Before shipping the product or disposing of it, discharge the batteries by running the product until they are flat. When transporting or shipping batteries, the person in charge of the product must ensure that the applicable national and international rules and regulations are observed.
  • Page 76 EZiSYSTEM, Safety Directions Warning Electromagnetic radiation can cause disturbances in other equipment. Although the product meets the strict regulations and standards which are in force in this respect, Cable Detection cannot completely exclude the possibility that other equipment may be disturbed. Caution There is a risk that disturbances may be caused in other equipment if the product is used in conjunction with accessories from other manufacturers, for example field computers,...
  • Page 77 Warning Electromagnetic fields can cause disturbances in other equipment, in installations, in medical devices, for example pacemakers or hearing aids and in aircraft. It can also affect humans and animals. Precautions: Although the product meets in combination with radio or digital cellular phone devices recommended by Cable Detection the strict regulations and standards which are in force in this respect, Cable Detection cannot completely exclude the possibility that other equip- ment may be disturbed or that humans or animals may be affected.

  • Page 78: Fcc Statement, Applicable In U

    EZiSYSTEM, Safety Directions FCC Statement, Applicable in U.S. Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 79 Labelling Locator EZiSYSTEM, Safety Directions...
  • Page 80 EZiSYSTEM, Safety Directions Labelling Transmitter...
  • Page 81 Conductive Rod a) End of Coil: Sonde mode Used to accurately pinpoint the end point of the rod. b) Rod: Line mode Flexible, Glass Fibre sheathed, which incorporates copper wires to conduct the signal. c) Connection Terminals Used to connect to the Transmitter. d) Frame Houses the flexible rod.
  • Page 82 EZiSYSTEM, Safety Directions Signal Clamp a) Transmitter plug connector b) Jaws c) Handle d) Cable Property Connection Set e) Mains plug connector f) In line isolator g) Transmitter plug connector...
  • Page 83 Technical Data 10.1 Locator i-Series Technical Data Typical detection range Mode Distance along conductor Power mode length of conductor Radio mode length of conductor Conductive Rod mode length of unwound rod Operating depth range Mode Range Power mode to 3 m / 10 ft Radio mode to 2 m / 7 ft Transmitter mode...
  • Page 84 EZiSYSTEM, Technical Data Operating frequencies Mode Frequency Power mode 50 Hz or 60 Hz Radio mode 15 kHz to 60 kHz 8 kHz mode 8.192 (8) kHz 33 kHz mode 32.768 (33) kHz Auto mode Power mode and Radio mode 512 Hz (xf models) 512 (512) Hz 640 Hz (xf models)
  • Page 85 Display panel • 48 segment bar graph • 5 mode indicators (Standard), 7 mode indicators (xf models) • Battery status indicator • Line depth indicator • Sonde depth indicator • Bluetooth indicator (where fitted) • Integrated backlight • Annual service indicator •...
  • Page 86 EZiSYSTEM, Technical Data Internal battery Type: 6 x LR6 (AA) alkaline Typical operating time: 40 hrs intermittent use at 20°C / 68°F; in 8 kHz mode or 33 kHz mode Instrument dimensions 85 mm/3.4 Inches 760 mm/30 Inches 250 mm/10 Inches Weight Instrument: 2.7 kg / 6 lbs...
  • Page 87 Environmental Type Description specifications Temperature Operating -20°C to +50°C -4°F to +122°F Storage -40°C to +70°C -40°F to +158°F Protection against Water, Dust IP54 (IEC 60529) and Sand Dust-protected Humidity 95% RH non condensing The effects of condensation are to be effectively counteracted by periodically drying out the product.
  • Page 88 EZiSYSTEM, Technical Data 10.2 Transmitter Technical Data Typical detection range Mode Output Induction mode Up to 1 W max. Connection mode t100 & t100xf Up to 1 W max. when connected to a buried service with an impedance of 300 Ω. Connection mode t300 &...
  • Page 89 Integral Speakers Audio Volumes: 85 dBA @ 30 cm Tone: 8 kHz mode: Low pitched tone 33 kHz mode: Higher pitched tone 512 Hz mode (xf models): Low pitched tone 640 Hz mode (xf models): Low pitched tone Induction mode: Pulsed tone Connection mode: Pulsed tone when poor or no current output, continuous tone when good connection Internal battery...
  • Page 90 EZiSYSTEM, Technical Data Environmental Type Description specifications Temperature Operating -20°C to +50°C -4°F to +122°F Storage -40°C to +70°C -40°F to +158°F Protection against With cover open IP65 (IEC 60529) Water, Dust and Dust-tight, Low power Sand water jets. With cover closed IP67 (IEC 60529) and secured Dust tight, Immersion up to 1 m.
  • Page 91 10.3 Conductive Rod Technical Data Typical detection range Both modes, Line and Sonde: Typical 3.0 m / 10 ft Tracing distance 30 m/99 ft; 50 m/165 ft; 80 m/263 ft (maximum). Reel length dependant Operating transmission Dependent on Transmitter frequencies Instrument dimensions 490 mm/19.3 Inches 210 mm/8.3 Inches...
  • Page 92 EZiSYSTEM, Technical Data Environmental Type Description specifications Temperature Operating -20°C to +50°C -4°F to +122°F Storage -40°C to +70°C -40°F to +158°F Protection against Frame IP54 (IEC 60529) Water, Dust and Dust-protected Sand Fully submersible Humidity 95% RH non condensing The effects of condensation are to be effectively counteracted by periodically drying out the product.
  • Page 93 10.4 Sonde Technical Data Operating transmission • 8.192 (8) kHz or frequencies • 32.768 (33) kHz Internal battery Type: 1 x LR6 (AA) alkaline Typical operating time: 40 hrs intermittent use at 20°C / 68°F; in 8 kHz mode or 33 kHz mode Instrument dimensions Ø38 mm/1.5 Inches...
  • Page 94 EZiSYSTEM, Technical Data Environmental Type Description specifications Temperature Operating -20°C to +50°C -4°F to +122°F Storage -40°C to +70°C -40°F to +158°F Protection against Water, Dust Fully submersible and Sand Humidity 95% RH non condensing The effects of condensation are to be effectively counteracted by periodically drying out the product.
  • Page 95 10.5 Maxi Sonde Technical Data Operating transmission • 8 kHz or frequencies • 33 kHz Internal battery Type: 3 x LR6 (AA) alkaline Typical operating time: 10 hrs continuous use at 20°C / 68°F; in 8 kHz mode or 33 kHz mode Instrument dimensions Ø55 mm/2.17 Inches 300 mm / 12 Inches...
  • Page 96 EZiSYSTEM, Technical Data Environmental Type Description specifications Temperature Operating -20°C to +50°C -4°F to +122°F Storage -40°C to +70°C -40°F to +158°F Protection against Water, Dust IP68 (IEC 60259) and Sand Fully submersible Submersion level: 3 bar pressure/30 m water Humidity 95% RH non condensing The effects of condensation are to be effectively...
  • Page 97 10.6 Property Connection Set Technical Data Operating transmission • 32.768 (33) kHz frequencies Instrument dimensions 80 mm/3.1 Inches 100 mm/3.9 Inches Weight Instrument: 0.15 kg / 0.3 lbs EZiSYSTEM, Technical Data...
  • Page 98 EZiSYSTEM, Technical Data Environmental Type Description specifications Temperature Operating -20°C to +50°C -4°F to +122°F Storage -40°C to +70°C -40°F to +158°F Protection against Water, Dust IP54 (IEC 60529) and Sand Dust-protected Humidity 95% RH non condensing The effects of condensation are to be effectively counteracted by periodically drying out the product.
  • Page 99 10.7 Signal Clamp Technical Data Operating transmission 32.768 (33) kHz frequencies when used with a signal transmitter set in 33 kHz mode. Instrument dimensions 250 mm/9.8 Inches 142 mm/5.6 Inches 100 mm/4 Inches Weight Instrument: 0.354 kg / 0.76 lbs EZiSYSTEM, Technical Data...
  • Page 100 EZiSYSTEM, Technical Data Environmental Type Description specifications Temperature Operating -20°C to +50°C -4°F to +122°F Storage -40°C to +70°C -40°F to +158°F Protection against Water, Dust IP54 (IEC 60529) and Sand Dust-protected Humidity 95% RH non condensing The effects of condensation are to be effectively counteracted by periodically drying out the product.
  • Page 101 10.8 Multi Clamp Technical Data Operating transmission • 8 kHz frequencies • 33 kHz • Mixed: 8/33 kHz • 512 Hz • 640 Hz Instrument dimensions 250 mm/9.84 Inches 129 mm/5.07 Inches 80 mm/3.15 Inches Weight Instrument: 0.82 kg / 1.8 lbs EZiSYSTEM, Technical Data...
  • Page 102 EZiSYSTEM, Technical Data Environmental Type Description specifications Temperature Operating -20°C to +50°C -4°F to +122°F Storage -40°C to +70°C -40°F to +158°F Protection against Water, Dust IP54 (IEC 60529) and Sand Dust-protected Humidity 95% RH non condensing The effects of condensation are to be effectively counteracted by periodically drying out the product.
  • Page 103 International Limited Warranty International Limited This product is subject to the terms and conditions set out in the International Limited Warranty Warranty which you can download from the Cable Detection home page at http://www.cabledetection.co.uk/internationalwarranty or collect from your Cable Detec- tion distributor.
  • Page 104 EZiSYSTEM, Functional Checks Appendix A Functional Checks Locator Functional Check Checking the function Before any tests can be carried out it is vital to check the status of the unit, its batteries and basic functionality. The following list is used to achieve this. 1.
  • Page 105 3. Battery / Functional self check If there is no response when the trigger is activated or the low battery illuminates (or flashes) after the Audio / Visual display test, the batteries will have to be replaced. Use alka- line batteries. Replace all of the batteries at the same time. Checking the The purpose of the following procedure is to verify the performance of the Locator.
  • Page 106 EZiSYSTEM, Functional Checks  If any of these tests give no response or a significantly different response from normal, the Locator should be returned for service. Functional test check list Functional Test Check List Unit: Serial Number: Comments: Locator... Test Operative Fail analysis Notes...
  • Page 107 Functional Test Check List 7. Batteries Replace Replace alkaline batteries if pack is exhausted (no response) or if the battery indicator light is illuminated or flashing after display test. Replace all batteries! 8. Power mode Return for repair Response width and peak value similar to test unit.
  • Page 108 EZiSYSTEM, Functional Checks Transmitter Functional Check Checking the function The purpose of the following procedure is to verify the performance of the signal Trans- mitter. Before any tests can be carried out it is vital to check the status of the unit, its batteries and basic functionality.
  • Page 109 2. Audio / Visual display test Turn on the Transmitter. All LED's will illuminate and the speaker will emit a tone. All LEDs must be operative and an audible output must be heard. 3. Battery check The battery indicator flashes to indicate a poor battery condition. Replace all batteries with four new LR20 (D) type alkaline batteries, or remove and recharge the battery pack if rechargeable batteries are fitted.
  • Page 110 EZiSYSTEM, Functional Checks Checking the The purpose of the following procedure is to verify the performance of the Transmitter. It is performance important that the test is conducted away from areas of electromagnetic interference. 1. Plug the Transmitter’s cable set into the connection socket. 2.
  • Page 111  • If the unit fails check the Transmitter's cable set is fully engaged and the clips are connected. • Repeated failure will indicate a faulty unit, which must be returned for service.  If any of these tests give no response or a significantly different response from normal, the Transmitter should be returned for service.
  • Page 112 EZiSYSTEM, Functional Checks Functional test check list Functional Test Check List Unit: Serial Number: Comments: Transmitter... Test Operative Fail analysis Notes 1. Casing Return for repair/ Casing should be free of Replace damage. 2. Labels Return for repair/ Body labels must be legible Replace and intact.
  • Page 113 Functional Test Check List 7. Induction mode Return for repair/ Reduced or no output signal. Replace 8. Connection Return for repair/ Faulty cable. mode; no change Replace in audio indica- tion 9. Connection Return for repair/ No output signal. mode; no change Replace in audio indica- tion...
  • Page 114 EZiSYSTEM, Functional Checks Conductive Rod Functional Check Checking the function The purpose of the following procedure is to verify the performance of the Conductive Rod. To carry out this test the following are required: • A Transmitter for generating the signal in the Sonde and Line mode tests •...
  • Page 115 Functional test check list Functional Test Check List Unit: Serial Number: Comments: Conductive Rod... Test Operative Fail analysis Notes 1. Sonde mode: Repair or replace Faulty cable. Transmitter audio cable set output does not go continuous 2. Sonde mode: Return for repair/ One or both internal wires Locator does not Replace...
  • Page 116 EZiSYSTEM, Functional Checks Sonde Functional Check Checking the function The purpose of the following procedure is to enable a user to verify the performance of the Sonde. To carry out this test the following are required: • A Locator to detect the signal. •...
  • Page 117 1. Switch sonde on and activate 33kHz mode. 2. Set Locator to 33 kHz mode and aim at Sonde (see diagram). 3. At 2 m/6.56 ft the Locator must be at maximum. 4. Repeat this with Sonde and Locator in 8 kHz. 2 m/6.56 ft 5 m/16.4 ft 5 m/16.4 ft...
  • Page 118 EZiSYSTEM, Functional Checks Functional test check list Functional Test Check List Unit: Serial Number: Comments: Sonde... Test Operative Fail analysis Notes 1. Casing Fail Casing should be free of damage. 2. Screw thread and Fail Screw thread must be intact seal and seal in place.
  • Page 119 Appendix B World Frequency Zones South America North America Argentina 230 V / 50 Hz Canada 120 V / 60 Hz Bolivia 110 V / 50 Hz United States 120 V / 60 Hz Brazil 110-127-220 V / 60 Hz Mexico 120 V / 50 Hz, 60 Hz Chile...
  • Page 120 EZiSYSTEM, World Frequency Zones Europe Albania 230 V / 50 Hz Slovenia 230 V / 50 Hz Austria 230 V / 50 Hz Spain 230 V / 50 Hz Belgium 230 V / 50 Hz Sweden 230 V / 50 Hz Belarus 230 V / 50 Hz Switzerland...
  • Page 121 Africa Algeria 127-220 V / 50 Hz Niger 220 V / 50 Hz Angola 220 V / 50 Hz Nigeria 230 V / 50 Hz Benin 220 V / 50 Hz Rwanda 220 V / 50 Hz Botswana 220 V / 50 Hz Senegal 110 V / 50 Hz Burkina Faso...
  • Page 122 EZiSYSTEM, World Frequency Zones Asia Abu Dhabi 230 V / 50 Hz Oman 240 V / 50 Hz Afghanistan 220 V / 50 Hz Pakistan 230 V / 50 Hz Armenia 220 V / 50 Hz Philippines 110-220 V / 60 Hz Azerbaijan 220 V / 50 Hz Qatar...
  • Page 123 Index Operating ............. 100, 102 Storage ............100, 102 Conductive Rod Sonde Functional Check ............114 Operating ............94, 96 Storage ............94, 96 Locator Transmitter Functional Check ............104 Operating ............... 90 Storage ..............90 Transmitter Operating depth range ............ 83 Functional Check ............
  • Page 124 Total Quality Management: Our commitment to total customer satisfaction. Cable Detection Ltd, Staffordshire, UK, has been certified as being equipped with a quality system which meets the International Standards of Quality Management and Quality Systems (ISO standard 9001). Ask your local Cable Detection dealer for more information about our TQM program.
