Summary of Contents for FiveCubits Tracklt VMX:TREQ MDT
- Page 1 VMX: TREQ MDT Version: 2.0 Hardware Installation & Configuration 03/04/19...
- Page 2 VMX Installation Guide The VMX device is the first version of TrackIt's vehicle-mounted devices. Some of its distinguishing features are the cellular antennas and GPS puck included with the device. Later versions of this device and their installation guides are available on the Devices page. Overview In this installation guide, the main steps for performing a field installation of the VMX: TREQ MDT device include the following:...
-
Page 3: Hardware Requirements
VMX Installation Guide Hardware Requirements The VMX: TREQ MDT unit comes with a mobile data terminal, cellular antennas, power cables, GPS, and a mounting bracket. Hardware Components Verify the following components are included in the installation kit: Component VMX: TREQ MDT Description A mobile data terminal meant for interfacing with TrackIt. - Page 4 VMX Installation Guide Component Power, ground, & ignition cable OR 9/6 pin engine diagnostics cable with power, ground, and ignition. (OBDII connector may be included for use with Mack trucks, model year 2014+.) Description The power, ground, and ignition cable connects the MDT to the engine's power.
-
Page 5: Required Tools And Equipment
VMX Installation Guide Required tools and equipment Mounting fasteners for the MDT Fasteners for mounting the GPS antenna Cable ties for securing cables to the vehicle Fuses to protect device Before beginning the installation process, refer to our Installation Warnings for the driver tablet, as they are relevant for the VMX: TREQ MDT installation and our BYOD &... - Page 6 VMX Installation Guide Install the VMX Prior to securing your mount and dock, review the following Installation Warnings. The installation for the VMX: TREQ MDT covers the following steps: Securing the mount to the vehicle Mounting the VMX: TREQ MDT MDT Installing the GPS puck antenna Connecting the power cable (Optional) Installing the engine diagnostics cable For installation of the cellular antenna, please follow the installation instructions contained...
- Page 7 VMX Installation Guide Securing the mount to the vehicle Because securing the mount to a vehicle's dashboard is subject to many variables and because installers are expected to have previous experience with this process, these instructions do not include specific steps for this process. However, see the tips below for additional information. Helpful tips Before securing the mount to the dashboard, find the optimal spot for the tablet, tablet dock, and mount to be positioned.
- Page 8 VMX Installation Guide Mounting the VMX: TREQ MDT After the mount is secured to the vehicle, attach the VMX: TREQ MDT to the mount with two screws. Ensure the mount is angled diagonally to meet the screw-in points correctly. Installing the GPS puck antenna We recommend testing the VMX: TREQ MDT in the service area before permanently installing the antennas.
-
Page 9: Connecting The Power Cable
VMX Installation Guide Connecting the power cable 1. Connect the power cable with the DB26 pin connector to the back of the MDT. The smaller, white molex end of this cable will be used to fish down to the location of the fuse box. This corresponding mate of the 3 wire power cable will plug into the power pigtail. - Page 10 VMX Installation Guide Engine diagnostics (optional) 1. After fishing the Pigtail cable through the truck down to the location of the ECU plug, connect it to the engine diagnostics cable as shown below. 2. Plug the end of the Engine diagnostics cable show below into the ECU plug of the vehicle (either a 9-pin or 6-pin).
