BLAST FREEZER

BLAST CHILLER

ISTRUZIONI D'USO E MANUTENZIONE

ISTRUCTIONS FOR THE USE AND MAINTENCE

ISTRUCTIONS POUR L'UTILISATION ET LA MAINTENANCE

Table of Contents

Need help?

Do you have a question about the Freezy 5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Nemox Freezy 5

Page 1 BLAST FREEZER BLAST CHILLER ISTRUZIONI D’USO E MANUTENZIONE ISTRUCTIONS FOR THE USE AND MAINTENCE ISTRUCTIONS POUR L’UTILISATION ET LA MAINTENANCE...
Page 2 INDEX INTRODUCTION REGULAR MAINTENANCE EXTRAORDINARY MAINTENANCE INSTALLATION INSTRUCTIONS INSTALLATION RECOMMENDATIONS FOR CORRECT USE INFORMATION FOR A CORRECT WASTE ELECTRONIC CONTROLLER WORKING...
Page 3: General Safety Standards
INTRODUCTION The manifacturer would like to thank you for having chosen its products and we are sure that you will be more than satisfied with their performance. To help maintain efficiency and performance in time, we have prepared this manual that describes the correct use and maintenance of the Blast Chiller Freezer.
Page 4: Regular Maintenance
TECHNICAL ASSISTANCE Thanks to the network of concessionaires and authorised service centres, the manufacturer guarantees its customers an after-sales service. REGULAR MAINTENANCE WARNINGS Regular maintenance work can be carried out by non-specialised personnel who, however, must always adhere to the instructions given in this manual. Before cleaning or servicing the chiller lock-off the power supply.
Page 5: Extraordinary Maintenance
When the Chiller is out of service for a long period of time take the following measures: Remove the plug from the power socket; Remove all food and clean the inside of the Chiller and all accessories; Buff all the stainless steel surfaces with a cloth moistened with vaseline oil to give a protective coating;...
Page 6: Installation Instructions
WASTE DISPOSAL AND SCRAPPING Storing waste: It is possible to temporarily store special waste products that are to be scrapped. However, the user must observe and adhere to the local governing laws regarding waste management. Macro – dismantling the Chiller: Each country has its own waste management laws, therefore the user must observe and adhere to the local governing laws where the Chiller is to be scrapped.
Page 7: Installation
The Chiller has no dangerous corners, sharp and cutting surfaces or protruding parts. All safety guards on moving parts or electrics are screwed to the cabinet. These guards avoid any form of accidental contact with parts that present a risk to the user. Always respect safety standards: Do not touch the Chiller with wet hands or feet;...
Page 8: Recommendations For Correct Use
The socket is earthed and frequency and tension correspond to the information given on the metal plate. If in doubt about earthing, call in a qualified electrician to check wiring. A suitable thermomagnetic switch must be provided between the power cable and electricity line with at least a 3 mm break contact.
Page 9: Blast Chilling
CYCLES BLAST CHILLING The blast chilling cycle rapidly lowers the temperature of the food to a minimum of +3 °C. Blast chilling is for food that will be consumed within a few days. BLAST FREEZING Blast freezing is for storing food for longer periods of time. When blast freezing the water content in the food is micro crystallized so when defrosting the food is not altered in any way maintaining both its appearance and nutritional value.
Page 10 INFORMATION FOR A CORRECT WASTE Directive on the electrical appliances waste (WEEE) (RoHS) In the optical of the respect of the ambient of the health and based on the sanctioned dispositions from the Directive 2002/95/CE of the European Union in matter of limitation to the use of dangerous substances (RoHS), regarding: LEAD ( Pb ) MERCURY ( Hg )
Page 11 ELECTRONIC CONTROLLER WORKING Important Carefully read these instructions before installation and use. Carefully adhere to all warnings provided concerning installation, wiring and connection to the mains electrical supply. Installation Panel with snap-on brackets provided; measurements in mm; measurements in mm. The maximum depth is 89.5 mm whatever the type of connection and refers to models with Faston connections (straight female Faston correctly inserted).
Page 12: Wiring And Electrical Connection
diffusers etc), direct sunlight, rain, humidity, excessive dust, mechanical vibrations and jolts. • in conformity with the safety standards in force the protection provided to prevent contact with the electrical parts is guaranteed by installing the system correctly. All protective parts must be mounted and secured in place so that they cannot be removed without the aid of a tool.
Page 13: User Interface
• if this system is moved from a cold location to a warmer location, condensation may form on the inside; wait for approximately an hour before powering. • check system supply voltage, frequency and wattage correspond to the mains electrical supply •...
Page 14 when blast chilling the evaporator fan is managed by parameter F0 for storage the evaporator fan is managed by parameter F2 when defrosting the evaporator fan is turned on. With the chiller in stand-by only manual defrosting is possible; if the function managed by relay K2 is the evaporator fan (parameter u0=1) the evaporator fan is turned on and when dewatering this fan is turned off.
Page 15 Before running a temperature controlled chilling cycle a test is run to check that the needle probe has been inserted correctly (refer to paragraph 3.6). To restart utilising the same settings as the last cycle run: make sure the system is in “stand-by” mode and that no procedure is running and that another cycle has not be selected •...
Page 16 chiller internal temperature is displayed • LED and are on parameter r9 defines working setpoint • press several times: “PoS” is displayed - escape this procedure or do not use for 15 seconds To suspend the cycle: • press for 2 seconds: Negative temperature timer controlled chilling and storage To start the cycle: check that the system is in “stand-by”...
Page 17 “nEg” is displayed - escape this procedure or do not use for 15 seconds To suspend the cycle: • press for 2 seconds: Positive temperature with temperature controlled chilling and storage To start the cycle: check that the system is in “stand-by” mode and no other procedure is running •...
Page 18 • press several times: - to turn off the buzzer - the extra chilling time elapsed over the maximum blast chilling time is displayed - displays chiller internal temperature - “PoS” is displayed - escape this procedure or do not use for 15 seconds when the temperature reading detected by the needle probe reaches end of chilling temperature: - the chiller goes into storage mode...
Page 19 During blast chilling: needle probe temperature reading is displayed • LED is on parameter r4 defines end of chilling temperature parameter r6 defines maximum chilling time parameter r8 defines working setpoint • press several times: - remaining chilling time is displayed “nEg”...
Page 20 “nEg” is displayed - escape this procedure or do not use for 15 seconds To suspend the cycle: • press for 2 seconds: Test for checking that the needle probe is inserted correctly Before running a temperature controlled chilling cycle a test is run to check that the needle probe has been inserted correctly.
Page 21 • press for 4 seconds: “PA” is displayed To access the second level: access the first level: • press to select “PA” • press • press within 15 seconds to set “-19” • press or do not use for 15 seconds. •...
Page 22 controlled blast chilling cycle has been completed if this LED is flashing, a timer controlled blast chilling and storage cycle has been selected. LED temperature controlled blast chilling • if this LED is on and LED is off, a temperature controlled blast chilling cycle is running •...
Page 23: Diagnostic System
CODE MEANING Minimum temperature alarm Remedies: • check chiller internal temperature • refer to parameters A1 and A2 Results : • the system continues to work regularly Maximum temperature alarm Remedies: • check chiller internal temperature • refer to parameters A3 and A4 Results : •...
Page 24: Technical Specifications
• access parameter P0 • check that the probe is intact • check the connection system – probe • check chiller internal temperature Results when the error occurs with the system in “stand-by”: • if parameter C11 is set at 0, no cycle can be activated •...
Page 25 Degree of protection of faceplate: IP 65. Connections: screw terminals, (power supply, inputs and outputs), 6-pole connector (serial port upon request); pull-out terminals (power supply, inputs and outputs) upon request. Workplace temperature: from 0 to 55°C (10….. 90% humidity without condensation).
Page 26 negative temperature chilling (temperature detected by the needle probe) Min. maximum time for positive temperature controlled blast chilling Min. maximum time for negative temperature controlled blast chilling -99.0 -99.0 °C/°F(1) working setpoint during positive temperature blast chilling (chiller compartment temperature) -99.0 -99.0 °C/°F(1)
Page 27 unit measurement temperature (2) 0 = °C 1 = °F needle probe enabled 1 = yes PARAM MIN. MAX. U.M. DEF. MAIN REGULATOR 15.0 °C/°F(1) differential for parameters r7, r8, r9 and rA time for positive temperature timer controlled blast chilling time for negative temperature timer controlled blast chilling -99.0...
Page 28 -99.0 °C/°F(1) -20.0 working setpoint during storage after negative temperature blast chilling (chiller compartment temperature) enable negative blast chilling cycle and storage 1 = yes °C/°F(1) difference (temperature detected by the needle probe – chiller compartment probe” for the first step when testing the needle probe inserted...
Page 29 C6 (only if C11 =0) -{}-Min compressor start-up time during error alarm chiller compartment probe when in storage mode; refer to C4 (only if C11 =0) compressor start-up time during error alarm chiller compartment probe when in negative temperature storage mode;...
Page 30 IF THE ERROR OCCURS DURING A TEMPERATURE CONTROLLED BLAST CHILLING CYCLE – needle probe functions as both needle probe chiller compartment probe and the blast chilling cycle continues; we recommend that parameter i0 is set to 2 (COMPRESSOR PROTECTION) IF THE ERROR OCCURS DURING STORAGE –...
Page 31: Digital Inputs
type of maximum temperature alarm 0 = no alarm 1 = refers to parameters r9 and rA (namely “r9 + A4” and “rA + A4”) delay in temperature alarm from when chiller goes into storage mode temperature alarm delay delay in maximum temperature alarm after dewatering...
Page 32 enabled the evaporator fan is turned off (maximum for the time i3 or when the input is disabled) 1 = INPUT MICROPORT – in this case parameters i1, i2 and i3 are active; when the input is enabled the compressor is shut- down and the evaporator fan is turned off (maximum for the time i3 or when the input is disabled)
Page 33 PARAM MIN. MAX. U.M. DEF. function managed by relay K2 (refer to paragraph 2.3) 0 = defrosting 1 = evaporator fan U.M. SERIAL NETWORK (MODBUS) baud rate 0=2400 baud 1=4800 baud 2=9600 baud 3=19200 baud equality 0= none 1=odd 2=even PARAM MIN.
