Downee MAX GATE HARDWARE DPLLEVER Quick Start Manual

- Suits 40 - 125mm Posts
- Left or Right Handed
- Single or Double Gates
- Lock/Unlock Both Sides
MAGNET
LEVER
LATCH
START
Left or
The Latch comes ready
for Right-Handed gates. A
Right?
few simple steps and the
- Suits 40 - 125mm Posts Latch is ready for
Left-Handed gates.
- Left or Right Handed
- Single or Double Gates
LEFT
- Lock/Unlock Both Sides
POST
RIGHT
GATE
Keeper
Screw
DPLLEVER
To change the
Latch for
left-handed
install.
Slide Keeper
off the
Mount and
rotate it
180° degrees.
DPLLEVER
GATE
POST
MAGNET
LEVER
LATCH
- Suits 40 - 125mm Posts
- Left or Right Handed
- Single or Double Gates
- Lock/Unlock Both Sides
Mount Keeper
Keeper
Mounting Screw
Mark Latch
Vertical Adjustment
position
Locking Screw
on SIDE
of gate
Horizontal Adjustment
Locking Screws
Both Sides
Mounting Screw
FRONT
template
DPLLEVER
Slide bottom cover
out of Latch.
Slide it into the top.
Keeper
Mounting Screw
Vertical Adjustment
Locking Screw
Horizontal Adjustment
Locking Screws
Both Sides
Mounting Screw
Use both FRONT and
BACK templates to mark
the mounting holes.
Drill a Ø19mm hole at
the centre (marked 3/4")
on the both
.125
(1/8")
templates.
Drill the Ø3mm pilot
holes (marked 1/8")
at each corner of the
template.
08/09/16
FIG. 8
