Page 2 WD011810822 Thanks for you purchasing a WIDO product. We are confident that you will appreciate the quality of the product and you will be entirely satisfied with your purchase. Please read carefully the user safety and operating instruction on how to operate this product correctly...
Page 3 WD011810822...
Page 4 WD011810822...
Page 5: Component List
900W PLANER COMPONENT LIST 1) Cutting depth adjuster 2) Dust exhaust outlet 3) Planing depth scale 4) On/off switch 5) Lock-off button 6) Hand grip areas 7) Rear base plate 8) Belt cover 9) Front base plate 10) V-groove 11) Base plate stander (See Fig 3) 12) Blade drum (See Fig 9) 13) Blade clamp (See Fig 9) 14) Cutter blade (See Fig 9)
Page 6: General Power Tool Safety Warnings
900W PLANER GENERAL POWER TOOL SAFETY WARNINGS: Warning: Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
Page 7 900W PLANER of the power tool in unexpected situations. f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
Page 8: Double Insulation
900W PLANER rear base must lie flat on the surface. 10) Do not put your fingers into the dust exhaust outlet. Use a wooden stick to unblock any material. 11) Wait for the cutter to stop before setting the tool down. An exposed cutter may engage the surface leading to possible loss of control and serious injury.
Page 9: Technical Data
900W PLANER TECHNICAL DATA: Model WD011810822 Voltage 110-120V AC 220-240V AC Frequency 50-60Hz 50-60Hz Power input 900W 900W No load speed 16000/min 16000/min Planing width 82 mm 82 mm Cutting depth Double insulation Machine weight 2.5Kg 2.5Kg OPERATING INSTRUCTIONS NOTE: Before using the tool, read the instruction manual carefully.
Page 10: Maintenance
900W PLANER throughout the entire cutting operation. CAUTIONS: When the planer is suspended with one hand after finishing the planning operation, ensure that the cutting blades of the planer do not contact or come too near your body. Failure to do so could result in serious injury.
Page 11: Environment Protection
900W PLANER 4. Always store your power tool in a dry place. 5. Keep the motor ventilation slots clean. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. ENVIRONMENT PROTECTION Waste electrical products should not be disposed of with household waste.
Page 12: Explosive View
900W PLANER EXPLOSIVE VIEW...
Page 13: Part List
900W PLANER PART LIST Q’TY Q’TY DESCRIPTION DESCRIPTION Screw Housing Belt cover Cord clamp Screw Screw Belt Switch Big wheel Handle Cover Circlip Screw Bearing Screw Screw Motor rear cover Bearing holder Screw Blade drum Flange Blade clamp Bearing Blade Carbon brush Blade holder Brush holder...
