F5 Maintenance And Service; Function Description - Baxtran COVER-ARX User Manual

F3 ENERGY-SAVING PARAMETER SETTING
F3.1 Time-out Screensaver Time Setting
Selectable Parameters: 0~ 99 minutes, (default value: 30 minutes) If set
to be 0, this function shall not be allowed.
During the screen protection, the display will randomly show " ".
F3.2 Energy-saving Time Setting for Auto Power-off
Settable Parameters: 0~250 minutes. (default value: 150 minutes) If set
to be 0, this function shall not be allowed.
F3.3 Display Brightness Contro l Selectable
Parameters: 0---- low light level
1 ---- middle light level (default value) 2
---- high light level
F3.4 Real-time clock, date setting
F3.5 Real-time clock, time setting
F4 PRINTER CONFIGURATION (NON MODIFY)
F4.2.4 Printing languages selection
CHI: CHINESE \ ENG: ENGLISH \ FRA: FRENCH \ ESP: SPANISH \ ITA: ITALIAN \ POR: PORTUGUESE

F5 MAINTENANCE AND SERVICE

F5.1 Key test
Instrument display¡, press
, [lb/kg] and in order, and the instrument displays
test.
F5.2 Display screen test
All strokes of meter display will have self-inspection, to observe whether there is lacks of strokes. Press
or to quit test of display screen.
F5.3 Display current internal code
The display will show internal code of current instrument after smoothing. Press
VI FUNCTION DESCRIPTION
WEIGHT MAINTENANCE FUNCTION F2.1 = 1
Operation method
In normal weighing state, press
lamp is on. Only when weight setting value≥F2.2 is displayed, weight maintenance operation is effective. Otherwise, it will return to
weighing state after invalid operation information [--no--] is shown for a second.
If weight is in locked state, press
If it is in weight locking state, refuse to remove skin, clear skin and setting operation.
, , ,
on the operation panel, the will instrument lock display weight of the current scale, and "Hold" indi- cation
again to cancel locking of weight and return to normal weighing state, and "Hold" indication lamp is off.
, , , ,
or
and , press to quit key
to quit the interface.
