Outdoor Wireless IP Camera
SC10IP
Quick Start Guide
Features
•
H.264 video compression
•
Supports P2P, DDNS and cloud service
•
Two‐way audio
•
Supports mobile devices
•
Supports ONVIF2.0 (Open Network Video Interface Forum 2.0)
•
Support Wi‐Fi connection
•
Remote control of the camera
•
Water resistance
•
Infrared LED for night vision
•
Supports DDSN and email alarm
•
Video recording and screenshot function
What's included
•
SC10IP Camera X1
•
AC adapter X1
•
CD with applications X1
•
Screw plug X3
•
Screw X3
•
Quick Start Guide
•
Android installation guide
•
PC installation guide
•
Warranty Card
Parts
Advertisement
Table of Contents
Summary of Contents for OfficeOne SC10IP
- Page 1 Outdoor Wireless IP Camera SC10IP Quick Start Guide Features • H.264 video compression • Supports P2P, DDNS and cloud service • Two‐way audio • Supports mobile devices • Supports ONVIF2.0 (Open Network Video Interface Forum 2.0) • Support Wi‐Fi connection • Remote control of the camera • Water resistance • Infrared LED for night vision • Supports DDSN and email alarm • Video recording and screenshot function What’s included • SC10IP Camera X1 • AC adapter X1 • CD with applications X1 • Screw plug X3 ...
-
Page 2: Hardware Installation
1. DC power supply in 2. Network connector 3. Waterproof case 4. LEDs 5. WiFi antenna Hardware Installation 1. Install the antenna. 2. Connect the DC power cord to the camera DC connector and plug the AC adapter into a live mains outlet. 3. Connect the camera and a router, modem or switch with a network cable. 4. Check the network connector if the green light stays on and the yellow light blinks as the data is transmitted. If there are no lights on, make sure the connection is made properly. 5. Your computer should be connected to the same router, modem or switch to configure the camera for first time. Software Installation and set‐up 1. Copy the files in the included CD to the HDD in your computer. 2. Go to the folder in the HDD that you copied to. 3. Double‐click General Device Manager to install the device manager program for SC10IP. ... - Page 3 4. Launch ‘Device Manager’. 5. Click on ‘IP search’ to find out the IP address and port number of the camera. 6. Select a camera in the list to see the network settings of the camera. 7. Confirm that your camera’s Subnet Mask, Gateway, DNS Server settings are the same as your computer’s settings. Also confirm your camera’s IP and computer’s IP are in the same range. If the settings are different, modify the settings and click on ‘Apply’. NOTE: The factory default network settings of SC10IP IP Address 192.168.1.10 Subnet Mask 255.255.255.0 Gateway 192.168.1.1 Username admin Password <blank> 8. Click on ‘Web Browse’ to connect to the camera in the internet browser. NOTE: Allow the internet browser (IE, Chrome, etc.) to install or use ActiveX or plug‐in if a window prompts. Logging in to the camera 1. Log‐in window will appear when connecting to the camera in the internet browser. ...
- Page 4 2. Enter User name (default : admin) and Password (default : <blank>) and click on ‘Login’. 3. Camera screen is displayed as below 4. Hover the cursor on an icon or a menu to see the description. Setting up Wireless LAN on the camera ...
- Page 5 1. Make sure your WiFi router supports and is set to IEEE802.11 b/g/n mode. 2. Click on ‘Device config’ to open the setting window. 3. Click on the ‘System’ icon and select ‘NetService’. 4. Select WiFi to open the WiFi setting window. ...
- Page 6 5. Click on ‘Search’ to scan available Wireless networks nearby. 6. Select the wireless network you want to use. 7. Confirm that all the network information is correct and enter password in ‘Share key’. 8. Enter the password. Select ‘OK’. ...
-
Page 7: Setting Up Email Notification
9. The camera will reboot to apply new settings. 10. Wait until rebooting finishes and carefully disconnect the network cable from the camera. 11. Connect your PC to the wireless network the camera is connected to. 12. Run ‘Device Manager’ and check if the camera appears in the camera list. Setting up DDNS Service NOTE: A valid DDNS account is required to set up DDNS setting. 1. Click on ‘DDNS service settings’ 2. Select a DDNS server from the list. Enter DDNS username and password. 3. Click on ‘OK’ to confirm the settings. 4. If DDNS is set up properly. You can connect to the camera via the internet. Setting up email notification You can set up your email account and server details to receive email notifications. ... - Page 8 1. Click on ‘Mail service settings’. 2. Enter correct email and email server settings. 3. Click on ‘OK’ to confirm. Setting up alarm service 1. Click on the alarm icon and select Video Motion. 2. Set the sensibility, internal and other options and click on ‘OK’. ...
- Page 9 Setting up SD card record schedule 1. Click on the Record icon and select ‘Record’. 2. Set up the record schedule. The video will be recorded according to the schedule. ...
-
Page 10: Specifications
Specifications Camera Lens 3.6mm, CMOS sensor Wi‐Fi 802.11 b/g/n IR distance Up to 20 metres Video 720P HD AC adapter DC 12V, 2A ... -
Page 11: Warranty
If your product is faulty or you are experiencing difficulties using this product and require assistance please call our customer assistance helpline as listed below: This product has been manufactured to the highest quality standards. This product is warranted to the original purchaser or gift recipient and is not transferable. - Page 12 – The product can be personally returned to the original place of purchase for product repair, replacement or refund. Please ensure the product is properly packaged so as to ensure, that no damage occurs to the product during transit. Also make sure that you have included an explanation of the problem.
