JA-PED 6B
6.5" 2 Way Pendant Speaker
Installation Instructions
Thank you for purchasing JA Audio speakers. We
take pride in our products and are committed to
provide years of entertainment pleasure. JA-PED
series is a 70/100V music distributed-line system
offering superb sound quality. This booklet covers
the necessary information for an intuitively easy
installation guide.
Contents: 1 speaker, 1 cover plate w/ 3 screws, 1 hanging kit
Advertisement
Related Manuals for JA Audio JA-PED 6B
Summary of Contents for JA Audio JA-PED 6B
-
Page 1: Installation Instructions
JA-PED 6B 6.5” 2 Way Pendant Speaker Installation Instructions Thank you for purchasing JA Audio speakers. We take pride in our products and are committed to provide years of entertainment pleasure. JA-PED series is a 70/100V music distributed-line system offering superb sound quality. This booklet covers the necessary information for an intuitively easy installation guide. - Page 2 Installation Instructions Unpack speaker Thread hanging or safety Attach snap hook by and Gripple cable cable through Gripple cable inserting one end through the mounting hardware. mechanisms as shown. hold on mounting bracket. Attach the hanging Connect signal wires Thread cable end(s) cable by securing it to (+) and (-) inputs.
- Page 3 Select desired tap position. Adjust speaker hanging height Place cover plate onto Switch is preset to maximum with Gripple cable mechanism. Pull top of speaker and slightly 70V (100V) mode. to tighten & press button on Gripple rotate until alignment cable as shown to loosen or adjust.
- Page 4 JA Audio warrants to the original retail purchaser This warranty may not be valid if the product was only that this JA Audio product will be free from purchased through an unauthorized dealer. This defects in materials and workmanship, provided...
