STUCCHI MULTISYSTEM Series Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

www.lightingaustralia.com.au/products/lighting-track/multisystem-48v-track
CONTENTS
1. General Information & Warnings
• Adapter Rotation Kit & Nipple
• Trimless Reinforcing Bracket
• Trimless Mounting Bracket
Safety Warnings for products and installation
All the described operations of this instruction page must be done by specialised personnel only,
shutting of the electrical power and respecting all national installation regulations and
guidelines. A.A.G. Stucchi allows the use of only A.A.G. Stucchi parts in applications where the
MULTISYSTEM© system is installed. These parts must be installed according to the installation
instructions.
The company as a manufacturer is not responsible for the safety and functioning of the system if
parts not belonging to it are used or if any deviation from the installation instructions occurs. It is
then the user's responsibility to ensure the electrical, mechanical and thermal compatibility
between the system and the fixtures used with it. The track, its components and also the
adapters can't be used with accessories without the Quality/Approval mark of the region. On
A.A.G. Stucchi track one can use only A.A.G. Stucchi connections. A.A.G. Stucchi connections
can only be used with A.A.G. Stucchi tracks. Do not exceed listing loading indicated in the
relevant section and respect fixing distances during the track mounting. This track system is Class
III and is not compatible with Class I track systems or Class III track systems from other
manufacturers. Insert the appropriate power circuit protections in order to prevent short circuits
or overloads.
MULTISYSTEM INSTRUCTIONS
For more details visit our website:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MULTISYSTEM Series and is the answer not in the manual?

Questions and answers

Summary of Contents for STUCCHI MULTISYSTEM Series

  • Page 1: Table Of Contents

    A.A.G. Stucchi track one can use only A.A.G. Stucchi connections. A.A.G. Stucchi connections can only be used with A.A.G. Stucchi tracks. Do not exceed listing loading indicated in the relevant section and respect fixing distances during the track mounting. This track system is Class III and is not compatible with Class I track systems or Class III track systems from other manufacturers.

  • Page 2: Multisystem Track

    Safety Warnings for products and installation - The use of NON SELV or U-OUT > 60V dc power supplies, drivers and components is strictly forbidden. A.A.G. Stucchi recommends the usage of an opto-insulated repeater dali compatible (eg. RP-DALI- 24-48V) - You can choose to use the 4 conductors of the track in 2 different modes: - 2 different power supplies (2 circuits, 0 –...

  • Page 3: Recessing Track Conductors

    Recessing track conductors Recessing track conductors The track bars with 1-2-3 m length are supplied with the copper conductors already recessed at each finished edge, to prevent them coming from into contact with one another in case of dual power supply or, if end caps are used, to prevent the copper conductors from coming into contact with them.

  • Page 4: Multisystem End Feeds & Connections

    MULTISYSTEM End Feeds & Connections: http://www.lightingaustralia.com.au/products/lighting-track/multisystem-48v-track/multisystem-48v-end-feeds- connection-joints-accessories End Power Feed There are two types of end power feeds: the non-polarised version (without mechanical key; codes 9501/… Fig.6) and the polarised version (with mechanical key on the left, code 9501-KL/… Fig.7 or on the right, code 9501-KR/…...

  • Page 5: Linear Joints

    Linear Joint There are two types of linear joints: the non-polarised version (without the mechanical key, code 9503-S/… Fig.15) and the polarised version (with mechanical key, code 9503-S-K/… Fig.16). If polarised linear joints are used, take special care when inserting the joint into the track; once it has been inserted with the key properly oriented, the joint must lie completely flush with the track without protruding, and the key must not interfere with the track (Fig.17).

  • Page 6: Multisystem Adapters

    MULTISYSTEM Adapter (2A-60V dc; 10N): www.lightingaustralia.com.au/products/lighting-track/multisystem-48v-track/multisystem-48v-adapters-and- accessories Adapter MULTISYSTEM adapters are available in two versions: - Magnetic version adapters are equipped with permanent magnets which provide a connection to the metal plate inside the track (Pic. 1). - Mechanical version adapters with automatic lock (Pic 1b) All MULTISYSTEM adapter series come in two versions;...
  • Page 7 Adapter Rotation Kit and M10 or M8 Nipples The luminaire can be fastened to the adapter using following accessories: S-9519/5 (Pic. 9) + S- 9519/M8 or S-9519/M10 (Pic. 10). If series 9529…M adapters are used, two rotation kits and two nipple kits must be ordered.

  • Page 8: Multisystem Trimless Track

    MULTISYSTEM Trimless Track Brackets: www.lightingaustralia.com.au/products/lighting-track/multisystem-48v-track/multisystem-48v-track-mounting- components Reinforcement Bracket for Trimless Tracks To fasten two sections of the trimless track, we recommend using bracket S-9500/314-B. Only screw one of the set screws G1 onto the bracket, making sure that it does not protrude from the lower side W of the bracket (Fig.

  • Page 9: Multisystem Track Fixing Accessories

    MULTISYSTEM Track Fixing Accessories: www.lightingaustralia.com.au/products/lighting-track/multisystem-48v-track/multisystem-48v-track- mounting-components Assembly Diagrams 11/7/2019...
  • Page 10 11/7/2019...
  • Page 11 11/7/2019...
