Neoware Capio Quick Start Manual

Capio
QUICK-START GUIDE
1.

Unpack

Your Capio is typically shipped with the following items:
• A keyboard
• A mouse
• A power cable
• A stand for stabilizing your Capio in a vertical orientation (attached).
• This Quick-Start Guide
2.

Setup

Your Capio can be setup in either a horizontal or vertical orientation.
If you are using your Capio in a horizontal orientation:
• The USB ports should be on the right-hand side of the appliance.
• The appliance can be used to support your monitor.
• Apply the clear rubber feet to the bottom of the appliance chassis.
If you are using your Capio in a vertical orientation:
• The USB ports should be closer to the bottom of the appliance.
• The stand should be connected to the appliance.
3.

Connections

1 2
1. Power Cord
2. Mouse PS/2
3. Keyboard PS/2
Connect the supplied power cord, mouse, and keyboard to the ports labeled 1, 2, and 3 respectively. Connect your monitor's cable to
the Video port (4).
4.

Power Up

1. Smart Card slot (reader optional)
In order to turn on your Capio, push in the circular on/off button on its front panel. To turn off your Capio, push the on/off button again.
neoware
www.
3 4
4. Video Port
5. Audio Line Out, Line In, Mic.
6. Parallel Port
1
2. Power Indicator
.com
5 6
2 3 4
3. Network Activity Indicator
H o r i z o n t a l
7 8
7. Serial Port
8. 10/100 BaseT Ethernet Port
5
4. On / Off Button 5. USB Ports
