- Page 1 Extend Distribute Innovate Velocitykvm Multi-Mode Fiber Extension Systems Multi-Mode Fiber Extension Systems An overview of the Velocitykvm Dual-link and Single-link, Multi-Mode Fiber Extension Systems -4, 5, 8, 24, 28, 34, 35 & 38 Milford, Connecticut, USA...
-
Page 2: How To Contact Us
Our company facsimile number is 1-203-783-9949. Please indicate the nature of the fax on your cover sheet and provide return contact information. PHONE: 1-800-291-3211 Visit us online at www.thinklogical.com for more PHONE: 1-800-291-3211 product information, current updates and the WEBSITE: WEBSITE: www.thinklogical.com www.thinklogical.com EMAIL: support@thinklogical.com complete line of Thinklogical™ products. EMAIL: support@thinklogical.com... -
Page 3: The Logical Solution
Velocity KVM products are ideally suited for a wide range of applications in the broadcast and post-production field, as well as command and control centers, universities, large scale digital signage and other commercial KVM applications. The Velocity KVM Multi-Mode Fiber Extender standard model from Thinklogical™ includes: Multi-mode fiber for extension distances up to 350 meters Two DVI Displays... - Page 4 Velocitykvm-4 STEP 5: If desired, connect your optional Velocitykvm-4 local keyboard & mouse by inserting the PS/2 or USB HID connectors into the VelocityKVM Multi-Mode Fiber Extension System – Single Head, Single Link DVI Transmitter’s local devices receptacles and Multi-Mode Fiber Extension System – Single Head, Single Link DVI USB HID or PS2 connect the optional local DVI display to the Keyboard/Mouse...
- Page 5 Velocitykvm-5 STEP 5: If desired, connect your optional Velocitykvm-5 local keyboard & mouse by inserting the PS/2 or USB HID connectors into the VelocityKVM Transmitter’s local devices receptacles and Multi-Mode Fiber Extension System – Single Head, Single Link RGB/DVI Multi-Mode Fiber Extension System – Single Head, Single Link RGB/DVI USB HID or PS2 connect the optional local RGB/DVI display to Keyboard/Mouse...
- Page 6 Velocitykvm-8 Velocitykvm-8 Multi-Mode Fiber Extension System – Dual-Link DVI Multi-Mode Fiber Extension System – Dual-Link DVI USB HID or PS2 QUICK START GUIDE QUICK START GUIDE Keyboard/Mouse Fiber-Optic Cables: L1: Data Tx to Rx and Video Primary L2: Data Rx to Tx L3: Video Secondary *STEP 2: Ensure that...
- Page 7 Velocitykvm-24 Velocitykvm-24 Multi-Mode Fiber Extension System – DVI Two Display Multi-Mode Fiber Extension System – DVI Two Display QUICK START GUIDE QUICK START GUIDE USB HID or PS2 Keyboard/Mouse Fiber-Optic Cables: L1: Data Tx to Rx and Video 1 L2: Data Rx to Tx L3: Video 2 *STEP 2: Ensure that...
- Page 8 Velocitykvm-28 Velocitykvm-28 Multi-Mode Fiber Extension System – Dual- & Single-Link DVI, Two Display Multi-Mode Fiber Extension System – Dual- & Single-Link DVI, Two Display QUICK START GUIDE QUICK START GUIDE USB HID or PS2 Keyboard/Mouse Fiber-Optic Cables: L1: Data Tx to Rx and Video 1 Primary L2: Data Rx to Tx L3: Video 1 Secondary L4: Video 2...
- Page 9 Velocitykvm-34 Velocitykvm-34 STEP 5: If desired, connect your optional local keyboard & Multi-Mode Fiber Extension System – Four DVI Displays Multi-Mode Fiber Extension System – Four DVI Displays mouse by inserting the PS/2 or USB HID connectors into the VelocityKVM-34 Transmitter’s local devices receptacles. QUICK START GUIDE QUICK START GUIDE Ensure all system functions are operating properly.
- Page 10 Velocitykvm-35 Velocitykvm-35 Multi-Mode Fiber Extension System – Three DVI Displays Multi-Mode Fiber Extension System – Three DVI Displays QUICK START GUIDE QUICK START GUIDE USB HID or PS2 Keyboard/Mouse Fiber-Optic Cables: L1: Data Tx to Rx and Video 1 L2: Data Rx to Tx L3: Video 2 L4: Video 3 *STEP 2:...
- Page 11 Velocitykvm-38 Velocitykvm-38 Multi-Mode Fiber Extension System – Two Dual-Link DVI Displays Multi-Mode Fiber Extension System – Two Dual-Link DVI Displays QUICK START GUIDE QUICK START GUIDE USB HID or PS2 Keyboard/Mouse Fiber-Optic Cables: L1: Data Tx to Rx and Video 1 Primary L2: Data Rx to Tx L3: Video 1 Secondary L4: Video 2 Primary...
- Page 12 Extend Distribute Innovate...
-
Page 13: Technical Specifications
KIT-000005-R Audio Kit contains the following: CBL000006-006FR 6 pin MiniDIN Male to Male Cable, 6FT (2) Each Thinklogical™ Velocity KVM system is designed to the following specifications: CBL000015-006FR USB A-B Cable, 6FT (2) CBL000016-006FR 3.5mm Male to 3.5mm Male Plug, 6FT (2)
