Auto power-off function
The amp has an auto power-off function. With this function, the amp is
automatically turned off if there is no input for approximately 1 hour. When the
amp is turned off, it is not turned back on, even if a knob or selector is operated.
After the amp is turned off, turn it on again.
NOTES:
1. The POWER switch is a momentary type. Momentarily move the switch
up for On and Down for Off. The switch will return to the centre position
once released.
2. Power may not turn on or off if the switch is released in a very short time.
3. When the input level is extremely low or there is very little change in
the sound, the auto power-off function may be activated. In addition,
depending on the settings and environment, the amp may interpret noise
as input, even if the guitar is not being played.
As the factory default setting, the auto power-off function is enabled.
Tip
Enabling/disabling the auto power-off function
1. While holding down the DELAY button, turn on the amp. The EFFECTS
button shows the current setting.
Enabled
2. Press the DELAY button to switch between enabling and disabling the
function.
3. Wait without performing any operation for a few seconds. The setting is
applied, and the amp automatically returns to normal operation.
Fonction de coupure automatique de l'alimentation
Cet ampli est doté d'une fonction de coupure automatique de l'alimentation.
Cette fonction met automatiquement l'ampli hors tension lorsqu'il ne reçoit
aucun signal et que vous n'utilisez aucune de ses commandes pendant environ
une heure. Une fois l'alimentation de l'ampli coupée par cette fonction, l'appareil
reste hors tension et ne répond à aucune manip. Pour utiliser à nouveau l'ampli,
remettez-le sous tension.
REMARQUES:
1. L'interrupteur d'alimentation est de type 'momentané'. Actionnez
l'interrupteur vers le haut pour mettre l'ampli sous tension et vers le bas
pour le mettre hors tension. L'interrupteur retourne en position centrale
quand vous le relâchez.
2. Il se pourrait que l'instrument ne se mette pas sous tension ou hors tension si
l'interrupteur est relâché après un délai trop bref.
3. En présence d'un signal d'entrée de niveau extrêmement bas ou d'un son
qui ne change pratiquement pas, la fonction de coupure automatique de
l'alimentation pourrait s'activer. En outre, selon les réglages et les conditions
de jeu, il se pourrait que l'ampli identifie un bruit présent comme un signal
d'entrée, même si vous ne jouez pas sur votre guitare.
La fonction de coupure automatique de l'alimentation est activée à la
Astuce
sortie d'usine.
Disabled
Activer/désactiver la fonction de coupure automatique de l'alimentation
1. Mettez l'ampli sous tension tout en maintenant enfoncé son bouton DELAY.
Le bouton EFFECTS indique le réglage actuel.
2. Appuyez sur le bouton DELAY pour alterner entre le statut Activé et
Désactivé.
3. Ne touchez aucune commande de l'amplificateur pendant quelques
secondes. Le réglage choisi est activé et l'ampli repasse automatiquement en
mode normal.
E F G S 1
Activée
Désactivée
