DATEQ SPL-D2 Manual Introduction The SPL-D2 unit is a separate sound-level meter. Besides it can be linked to the SPL5 limiter. The unit is a large LED display, showing the actual sound-pressure level. By means of the PC software it is possible to change the settings.
Page 2
Operation DATEQ SPL-D2 Manual Display connected to the SPL5 When the display is linked to the SPL5 the microphone values will be downloaded from the SPL5 automatically. Those values will be showed in the large display. The LED-bar functions as a VU-meter, the display gives the actual SPL.
Mic (measuring microphone) XLR- 3 female. To be used with the supplied measuring microphone only Jack 6,3 mm Jack. Datalink to the SPL-5 To connect the SPL-D2 to a computer Norm Measurement chain designed to function according specifications IEC-61672-1 class 2 Common...
