PVK-102 Pivot Table Stand
Quick Start Guide
This printed quick guide provides a quick walkthrough of the set up process.
Technical Spec
Net weight
Dimension (W * H * D)
Screw type
Material
Hinge module
Display support
Cable Management
Box Content
Item
Parts
1
Table stand
2
Table mounting screw
3
VESA plate screw
1
Mounting and Installation
1
0.75 kg
(1.65 lbs)
157 mm x 216 mm x 136 mm
(6.18" x 8.50" x 5.35")
M4
Steel
Tilt
Rotating holder (pivot)
Mounting pattern
Suggested signboard size
Maximum support weight
Yes
2
-23° ~ +151°
360°
100 mm x 100 mm / 75 mm x 75 mm
≤ 12"
1.2 kg (2.6 lbs)
3
2
Q'ty
1
2
4
