Solar Centre Edinburgh Instructions

Edinburgh Solar Stainless Steel Deck Lights
Solar tips:
W E
S
Ensure your solar
panel is South facing
or as near as possible
Your lights will not charge correctly if they are charged inside, behind glass or by using artificial light
Thank you for choosing The Solar Centre's Edinburgh Solar Stainless Steel Deck Lights. Please read these instructions carefully
before using your lights.
Always take care when installing your Edinburgh Solar Stainless Steel Deck Lights, especially when making modifications to your
property.

Solar Panel Installation

The Edinburgh has a powerful solar panel that charges the internal high capacity batteries during the day. At night the charge in the
internal batteries powers the deck lights.
Before installing your solar panel you'll need to consider the best place for it to receive the most amount of sunlight. Position the solar
panel in a South facing location that is not obstructed by buildings, fences, trees, sheds, bushes or the shadows that these create.
Please note that a poor solar panel location will drastically reduce the performance of your Edinburgh Deck Lights.
The solar panel must be be located within 2.8m of where you intend to position the first deck light and can be mounted with the spike
into soft ground. If the ground is hard please soften the ground with water and make a hole using a strong metal object before driving
your stake into that hole. Please note that any damage caused to your solar panel as a result of driving them into hard ground is not
covered by your warranty.
1. Push the spike into the ground
2. Attach the panel to the spike by sliding the pole over part of the
spike that's protruding.
3. Ensure the cable exits the solar panel from the bottom of the
panel to reduce any risk of water ingress. - see diagram ->

Installing the deck lights

Each Deck Light requires a 2.5cm (1") hole. The light must be inserted so the stainless steel top sits almost flush.
Each Light has 2 cables exiting the underside of the black light body. One cable has to be connected to the previous light using the
Quick Connect system, the other cable must reach to the next light. Each connector must be tightly connected by hand to ensure a
good connection.
Approx 1.5" (3.9cm)
Approx 1" (2.5cm)
Clean your solar
panel from time
to time
Approx
1.25"
(3.1cm)
(Set of 8)
Do NOT place your
solar panel in shaded
areas.
QUICK CONNECT
DAISY CHAIN
SYSTEM
Do NOT charge
behind glass
