bITalino R-IoT Quick Start Manual

Start
1
Here
BITalino R-IoT is pre-programmed
to connect to a network called "riot".
Data streams as Open Sound Control (OSC) messages
to IP address 192.168.1.100 through port 8888.
Have
3
Fun!
-
At this point the BITalino R-IoT
is already streaming data
over UDP and ready to use.
One of the tools you can use to acquire data
from the BITalino R-IoT is OpenSignals,
(as described in the next steps),
but any OSC-compatible software will work.
5
Enable Device
Press the
to manually add a device.
FOUND
192.168.1.100:8888
1. Set the computer's IP to static to match
the one that R-IoT expect to nd: 192.168.1.100.
2. On the text box type 192.168.1.100:8888
and then press enter.
By default BITalino R-IoT is configured to connect to a computer with the fixed IP address 192.168.1.100
on port 8888 over a network with SSID named "riot". These settings can be changed as shown
on the back of this guide. See the Connect to another network section.
forum.bitalino.com to share your thoughts and projects
DISCLAIMER BITalino is not a medical device nor is it intended for medical diagnosis; it is provided to you "as is" and we make no
express or implied warranties whatsoever with respect to its functionality, operability, or use, including, without limitation, any
implied warranties, tness for a particular purpose, or infringement. We expressly disclaim any liability whatsoever for any direct,
indirect, consequential, incidental or special damages, including, without limitation, lost revenues, lost pro ts, losses resulting from
business interruption or loss of data, regardless of the form of action or legal theory under which the liability may be asserted, even
if advised of the possibility of such damages.
©PLUX wireless biosignals 2019 | BITalino R-IoT MN Quick Start Guide 1.0.0 | 2019.09
Quickstart Guide
Quickstart Guide
button
0
Have any questions? Visit:
www.bitalino.com for software and documentation
bitalino@plux.info to talk with our team
Connect
2
Battery
Plug the battery onto the socket
found on the R-IoT block.
When the device is turned on, a red LED is lit
Then, it turnsgreen and blinks while it tries to nd
the Wi-Fi network. When it connects to that network,
the LED turns blue and stays on.
Launch
4
OpenSignals
Press to configure your device.
This will enable you to con gure your BITalino R-IoT
for data acquisition on OpenSignals.
6
Have Fun!
Press (record).
You should now be able to see the data stream
coming from the device
After stopping your recording, data can be saved
through the button; please refer to the
OpenSignals manual to learn all about its features.
