Summary of Contents for Kiddypix Mystery
- Page 1 USER MANUAL...
- Page 2 IMPORTANT INFORMATION To ensure the optimal functioning of your camera, please note the following important information: MicroSD card: • Please ensure your memory card is formatted in the camera before first using the card for the first time (Settings > Format). •...
- Page 3 Safety instructions: WARNING: The camera is not suitable for children under 36 months because of choking hazard. WARNING: Always protect your camera from falls, blows and bumps. • Keep a sufficient distance from objects that generate strong magnetic fields or radio waves, such as electrical appliances to prevent them from damaging the product or affecting the sound and image quality.
- Page 4 1. Power button 2. Page Up button 3. Display 4. Busy indicator light 5. Page Down button 6. Mode button 7. Speaker 8. Rear lens...
- Page 5 9. Photo shutter button 10. Fill light 11. Recording button 12. Front lens...
- Page 6 13. Micro USB 14. Micro SD card 15. Battery door switch 16. Battery door switch 17. Microphone...
-
Page 7: Battery Installation
1. Battery installation Slide the battery door lock as shown in the figure below to unlock and access the battery compartment. Insert 4 x AA batteries ensuring batteries are installed as indicated. 2. Memory card installation Insert the memory card into the card holder as indicated (not included). -
Page 8: Power On/Off
3. Power on/off Power on: Long-press the power button . The screen will turn on and the camera will enter standby. Power off: Hold on power button for 3 seconds until the camera turns off. Auto screen off: In order to maximize battery life, the camera display will automatically power off after an extended period of inactivity. -
Page 9: Photo Mode
5. Photo mode To take a photo, you can short-press photo button to enter photo mode. Short-press the photo button again to capture your photo. Short-press page up button or page down button to join different frame effects. Long press the mode button to set the camera timer to automatically take a photo after 5 seconds. Selfie function: To take a selfie, long-press the photo button to switch to the rear camera lens. - Page 10 6. Menu and playback mode While in video recording mode or photo mode, short-press the mode button Short-press the page up button and page down button to change modes . Short-press the mode button to confirm your choice. To exit the menu screen, short-press power button Video recording mode Photo mode Playback mode...
-
Page 11: System Settings
You can view your videos and photos in one of the following ways: 1. In the user menu select Playback mode, then press the page down or page up buttons to select the video or photo you would like to view. To playback a video, press the mode button to start. - Page 12 8. Connecting to PC Your camera has a ‘plug-and-play’ function. Once connected to your computer and turned on, your camera will appear as a removable hard disk. The removable disk icon will appear in the "My Computer" window. Note: During file download and transfer, do not disconnect your camera or remove the memory card as doing so may result in full data loss.
- Page 13 Storage medium Micro SD Card support up to 32GB (not included) USB port USB 2.0 Power supply 4 x AA battery (not included) Power save 1 min. / 3 min. / 5 min. / OFF Operating system Windows XP/Vista/7/8, Mac 10.8 requirements All product specifications are correct at time of print and are subject to change without prior notice.
- Page 14 CONFORMITY The manufacturer hereby declares that the CE marking was applied to the product Kiddypix Mystery/Galaxy in accordance with the basic requirements and other relevant provisions of the following CE Directives: 2014/53/EU 2011/65/EC RoHs 2014/30/EU EMV 2012/19/EC WEEE The EC Declaration of Conformity can be downloaded here:...
- Page 15 DISPOSAL Dispose of packaging For disposal, separate packaging into different types. Cardboard and board must be disposed of as paper and foil must be recycled. Disposal of Waste Electrical and Electronic Equipment and/or Battery by users in private households in the European Union. This symbol on the product or on the packaging indicates that this cannot be disposed of as a household waste.
- Page 16 Battery warning • Never dismantle, crush, or pierce the battery, or allow the battery to short-circuit. Do not expose battery being placed in high temperature environment, if battery leaks or bulges, stop continue to use. • Risk of explosion if battery is replaced by an incorrect type. •...
