Bullard 88VXRT User Manual

88VXRT can be ordered under the part number 88VXRTP
which includes an inner shell/plenum.
Installation Instructions
The 88VXRT Flex-Gear
®
respirators manufactured by Bullard. Install the 88VXRT suspension according to
the following instructions. Refer to the 88VX Series Airline Respirator User Manual
for additional information.

Removing Cape and Inner Shell from Respirator Helmet

To install the headband suspension, remove cape from helmet using the following
steps.
1. Open hinged window frame by lifting up on window latch.
2. Remove cape from helmet by lifting up on clamp and disengaging cape from
helmet groove (see Figure 1).
3. Turn helmet upside down to remove inner shell from helmet. Hook index finger
into loop on back of inner shell. Press thumb against helmet rim and pull loop
toward front of helmet, then pull shell up and away from helmet (see Figure 2).
This releases the inner shell.
Figure 1

Sizing

Turn ratchet knob until headband is at its largest size. Place suspension on your
head and adjust ratchet knob to a comfortable fit (Figure 3). An optional chin strap
is available for additional comfort and stability.
88VXRT Ratchet Suspension
ratchet suspension fits 88VX™ Series supplied-air
Figure 2
Ratchet
Figure 3
Knob
