Orbit Merret OMX 333UNI Quick Start Manual

OMX 333UNI
SETTING
Selection of measuring type/mode
1. by switching dipswitch no. 2 to position „ON"
type of input by flashing (table 1)
2. change of input type, LED „Lo" is green
signals the type of input by flashing (table 1)
3. by pressing button „Hi" our selection is confirmed and a next menu item can be accessed
4. setting the measuring range - LED „Lo" is red
and LED „Hi" signals the type of measuring range (table 2) or for input type „DU" it is the setting of minimum (if the slider is in a
static position, then by pressing button „Lo")
Tab. 2
LED „LO"
LED „HI" MODE
PM DC
±2 V ±30 mV
±5 V ±60 mV
±10 V ±1 V
0...20 mA ±20 V
4...20 mA ±40 V
4...20 mA (Er) ±80 V
±90 mA
±180 mA
5. by pressing button „Hi" our selection is confirmed and a next menu item can be accessed (if it exists for the given type), otherwise
there is return to type
6. setting of connection (only for type DU, OHM, Pt, Ni, Cu, T/C) - LED „Lo" does not light up
types of connection are accessed and LED „Hi"
(if the slider is in a static position, then by pressing button „Hi")
7. by pressing „Hi" selected setting is confirmed and dipswitch no. 2 can be switched to „OFF"
Setting of Limits 1 (2)
1. after pressing button „Hi" (for Limit 2 it is button „Lo") red LED „L 1" („L 2") starts flashing
2. set dipswitch no. 2 (for Limit L2 it is switch no. 1) to „ON"
3. on the OMX 333 input set the sinal to the level required for the Limit to be actuated
4. select your setting by pressing the „Hi" button and switch the dipswitch no. 2 to „OFF"
Setting of Analogue/Data output
1. by switching the dipswitch no. 1 to „ON"
1 2
of output by flashing (table 4) or the rate of analogue output (table 5)
2. by repeated pressing of button „Lo" the types of analogue output are accessed (rychlosti) and LED „Lo"
output (tab. 4) or the rate of data output (tab. 5)
3. by pressing „Hi" the selected setting is confirmed and a next menu item can be accessed (only for further setting of data output)
4. by repeated pressing of „Lo" button instrument's address can be set ang LED „Lo"
(table 5) (this procedure only applies to setting of data output)
5. our setting is confirmed by pressing „Hi" button and progarmming mode is exited by switching dipswitch no. to „OFF"
Changing analogue output (AO) range
1. OMX 333 AO is set by manufacturer. This procedure is for experienced users
2. by switching dipswitches no. 1 and no 2 to „ON"
3. to input terminals of OMX 333 connect signal of requested level which equals to minimum range of AO (for example 4 mA)
and by pressing „Lo" button this value is recorded, LED „Lo"
4. to input terminals of OMX 333 connect signal of requested level which equals to maximum range of AO (for example 20 mA)
and by pressing „Hi" button this value is recorded, LED „Hi"
5. by switching dipswitches no. 1 and 2 to „OFF"
Restoration of manufacturer's /user settings
1. this is a good way how to return to the original manufacturer's setting especially when making a mistake during the set
up process
2. by pressing buttons "Lo" and Hi" simultaneously for approx 2 s LEDs „Lo" and „Hi"
3. by switching dipswitches no. 1 and 2 to „ON"
4. by pressing button „Hi" restoration of manufacturer's setting is executed (linearisation table, if it had been entered, is deleted), by
pressing button „Lo" restoration of user settings including those which had been set via OM Link SW is executed, (linearisation table
remains)
5. by switching dipswitches no. 1 and 2 to „OFF"
1 2 programming mode is accessed - LED „Lo"
- by repeated pressing of button „Lo" input types are accessed step by step and LED „Hi"
- by repeated pressing of button „Lo" measuring ranges are accessed step by step
T/C OHM Pt
B 0...100 Ω Pt 100 - Eu
E 0...300 Ω Pt 500 - Eu
J 0...1,5 KΩ Pt 1 000 - Eu
K 0...3 KΩ Pt 100 - Us
N 0...24 KΩ Pt 50 - Ru
R 0...30 KΩ Pt 100 - Ru
S
T
L
signals the type of connection (table 3) or for type „DU" setting the maximum
, LED "Lo" an "Hi" flash in cycles
1 2
programming mode is accessed - LED „Hi"
signals by flashing the address of OMX 333
programming mode is accessed - LED „Lo" and „Hi" fl ash alternatively
1 2
fl ashes twice the normal rate
fl ashes twice the normal rate
programming mode is exitted
1 2
the rate of flashing increases
1 2
this mode is exitted
1 2
lights up and LED „Hi" signals the
Ni Cu DU - calib. of min
Ni 1 000/5 000 Cu 50/4285
Ni 1 000/6 000 Cu 100/4285
Ni 10 000/5 000 Cu 50/4260
Ni 10 000/6 000 Cu 100/4260
- by repeated pressing of button „Lo"
1 2
and both LED "Lo" and "Hi" flash in cycles
1 2
lights up and LED „Lo" signals the type
signals the the type of
1 2
start flashing alternatively
LED „L2" LED „Lo"
LED „L1"
L2 L1
OM Link
Button
„Lo"
Tab. 1
LED „LO"
LED „HI" TYPE
PM
DC
T/C
DU
OHM
Pt
Ni
Cu
Tab. 3
LED „LO"
LED „HI" CONNECTION
OHM/RTD T/C
Int. 1
2-wire Int. 2
3-wire Ext. 1
4-wire Ext. 2
Cold junction compensation (CJC)
Int. 1 measurement of CJC on instrument's terminals
Int. 2 measurement of CJC on instrument's terminals and anti-serial connection
of referential T/C
Ext. 1 the entire system wokrs in a uninamous and constant temperature
Ext. 2 with a compensation box and referential T/C
Tab. 4
LED „HI"
LED „LO" ANALOGUE OUTPUT
TYPE
0...2 V
0...5 V
0...10 V
±10 V
4...20 mA (Er)
4...20 mA
0...20 mA
0...5 mA
Tab. 5
LED „HI"
LED „LO" DATA OUTPUT
RATE ADDRESS
300 0
600 1
1200 2
2400 3
4800 4
9600 5
19200 6
38400 7
57600 8
115200 9
230400 10
11
Tab. 6
LED SYMBOL LEGEND
LED is off
LED is on
/
LED flashes
/
LED flashes twice with a shotr pause
LED „Hi"
Lo Hi
1 2
Button
„Hi"
Switch
OFF
ON
1 2
DU - calib of max
ADDRESS PB
0
1
2
3
4
5
6
7
8
9
10
11
