AHI Hardware TLM1661 Installation Instructions

AHI HARDWARE
7548 Cote de Liesse St-Laurent,
Qc H4T 1E7, Canada
Tel. 514 335-8281
Tel. 877-339-8281
info@ahi-arch.com
www.ahi-arch.com
ø
2 ⁄ "
1"
ø
2 ¼" 1"
FIGURE 1
Drill 2 1/8" hole at correct
backset using included
template
EXTERIOR
FIGURE 5
1.
Before installing the spindle, unscrew it 2 turns from the fully
tightened position, if the provided spindle does not have a center
screw, skip to gure 6
2. NOTE: The spindle must be inserted into the latch such that the stopper
disc rests against the latch on the interior side of the door, and that the
thin wall side of the spindle will align with the levers' set screws
Magnetic Latch Privacy Installation Instructions
FIGURE 2
Prepare frame for strike.
⁄ " X ⁄ "
1" X 2 ¼"
INTERIOR
STOPPER DISC
THIN WALL SIDE
STOPPER DISC
lock switch
FIGURE 3
To install the mag latch into
1.
the door, make sure that the
privacy lock switch in
centered and that the
threaded side (see g 4) is
facing the interior
EXTERIOR
FIGURE 6
1.
Insert the sub rose into the 2 1/8" hole respecting the above orientation
Place the levers onto the spindle but do not tighten the lever set screw
2. Use the supplied screws (choose correct size based on door trim) and tighten
into sub rose assembly
3. Remove the levers
1
2
FIGURE 4
In order to center the lock switch, the
1.
latch must be extended. To achieve this,
place the latch near the strike box
2 1/8" PRE-BORED HOLE
TOP
BOTTOM
TOWARDS
DOOR EDGE
INTERIOR
