TSI Instruments 854034 Installation Manual

INSTALLING THE POWER SUPPLY

INTO ENVIRONMENTAL ENCLOSURE
This guide will help you quickly install the Power Supply
for Environmental Enclosure Model 854030.
Unpacking the Power Supply
(854034) for the Environmental
Enclosure (854030)
1. Unpack the Power Supply (854034) for
Environmental Enclosure (854030) and verify that all
the items listed in the following table are present.
2. Contact TSI immediately if items are missing or
broken.
Qty. Item Description
1 Power Supply
1 Mounting Bracket
_______________
TSI and TSI logo are registered trademarks of TSI Incorporated.
Reference Picture
MODEL
User Replaceable Parts
Reference
Picture Description
Connector
2 Position
Spring Cage
SP 4/2
Power Supply
Ground
Power Supply
Connection
External AC Electrical Cord
The 854034 Power Supply will be shipped with a
country-specific External AC Electrical Cord configured
for plug receptacles in the country receiving the
instrument. Alternate External AC Electrical Cords can
be ordered referencing the part numbers below.
Part number Description of Cord End Plug
1303900 US
1303901 Euro
1303902 Australia/ China
1303903 UK/HK
1303904 Switzerland
854030
QUICK START GUIDE
Manu- Part
facturer Number
Phoenix 3042890
Contact
Phoenix 3042722
Contact
Phoenix 3042719
Contact
