- Page 2 Manual | Wireless DMX Transceiver Preface Thank you for choosing LTH PRO.fessional Wireless DMX Transceiver! Wireless DMX transceiver use 2.4G global open ISM band, license-free. Efficient GFSK modulation, 79 channel high-speed frequency hopping (FHSS) communication design, anti-interference ability. It’ s your reliable wireless DMX solution. Wireless DMX transceiver is now compatible with the world‘s leading wireless communications protocol.
- Page 3 Manual | Wireless DMX Transceiver 1. Introduction 1.1 Features • Wireless DMX transceiver use 2.4G global open ISM band, license-free. Efficient GFSK modula- tion, 79 channel high-speed frequency hopping (FHSS) communication design, anti-interfe- rence ability. It’s your reliable wireless DMX solution. •...
- Page 4 Manual | Wireless DMX Transceiver 1.4 Interface 1. DMX512 three-pin or five-pin male or female Caron 2. External power supply input 3. Status indicator 4. Key switch 5. Antenna...
- Page 5 Manual | Wireless DMX Transceiver 2. Operating Guide 2.1 Operating mode Wireless transceiver has two operating modes: configuration mode and run mode 1. Configuration mode: Press button before power up, when you see the white LED, then release the button to enter configuration mode. In this mode you can select air protocol. Each time you press the button, to switch the order of color in the table, choose a protocol, long press (>...
- Page 6 Manual | Wireless DMX Transceiver 2.2 Run mode: a) Powered directly into the run mode; b) In the configuration mode, long press (> 3S), see the white release the button to enter the run mode. Status Protocol Action Description Red, Green, bBlue, Wireless Groups Yellow, Cyan,bPurple WIDMX...
- Page 7 Manual | Wireless DMX Transceiver 2.3 Select Wireless Group Each time you press the button, The group switch. Only the same group transceivers can communi- cate with each other. NOTE: If you are sending or receiving radio signals, the first press to view current group, then press switch the group.
- Page 8 Manual | Wireless DMX Transceiver 3. Applications 3.1 One transmitter one receiver DMX signal input of a wireless transmitter output DMX signal from another of the same group or wireless receiver connected. 3.2 One transmitter to multiple receivers DMX signal input of a wireless transmitter DMX signal output from the same grouping or the other wireless receiver connected.
- Page 9 Manual | Wireless DMX Transceiver 3.3 Multiple transmitters to multiple receivers Plural sets of radio transmitters can be operated simultaneously, without disturbing each other. 3.4 Relay Mode Receiver and transmitter connected directly, and working with different grouping or connection, can act as a repeater or amplifier, can increase the effective working distance.
-
Page 10: Maintenance
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications made to this device not expressly approved by LTH GmbH may void the FCC authorization to operate this device. - Page 11 Das Lichttechnikhaus Vertriebs GmbH Rudolf-Diesel-Str. 3, D-89312 Günzburg Telefon +49 (0) 82 21 207 98-0 +49 (0) 82 21 207 98-69 E-Mail info@lth-gmbh.de www.lth-gmbh.de...
