Instruction Manual
Electric Jack
P/N 043-1001-HY-WH
Read this material before using this product.
Failure to do so can result in serious injury.
Save this manual.
1
CONTENTS
Important Safety Instructions and Warnings.................... 3
Product Specifications.................................................. 5
Product Overview......................................................... 5
Electric Jack Features/Operation.................................... 6
Trouble Shooting.......................................................... 9
Customer Service......................................................... 10
Warranty..................................................................... 10
2
Advertisement
Table of Contents
Related Manuals for Deltran Hyperion 043-1001-HY-WH
Summary of Contents for Deltran Hyperion 043-1001-HY-WH
- Page 1 CONTENTS Important Safety Instructions and Warnings……………….. 3 Product Specifications………………………………………….. 5 Instruction Manual Product Overview………………………………………………… 5 Electric Jack Electric Jack Features/Operation..……………………………. 6 Trouble Shooting…………………………………………………. 9 Customer Service………………………………………………… 10 Warranty…………………………………………………………… 10 P/N 043-1001-HY-WH Read this material before using this product. Failure to do so can result in serious injury. Save this manual.
- Page 2 IMPORTANT SAFETY INSTRUCTIONS & WARNINGS 6) Do not use rams as permanent supports. 1) SAVE THESE INSTRUCTIONS – This manual contains important safety and operating instructions for the Electric Jack, P/N 043-1001-HY-WH 2) Read all warning labels and instructions. Operating instructions must be understood before using equipment.
- Page 3 PRODUCT SPECIFICATIONS ELECTRIC JACK FEATURES/OPERATION Electric Jack Input Voltage 12 Volt DC Rated Power 150 Watts Maximum Current 13 Amps Fuse 15 Amp, 250 Volt Maximum Lifting Weight 3 Tons (6000 pounds) Lifting Height Range 6-17½ inches (155 – 444mm) Working Temperature 5 - 122°F (-15 - 50°C) PRODUCT OVERVIEW...
- Page 4 Safety Release Valve Operation: 12V Power Adapter with Quick Disconnect 1) If you lose power use the safety valve to descend the Jack Ram 1) Use the supplied 12V power adapter to supply power to the jack. 2) Remove the dustproof plug to expose the hex screw. 2) If the red LED is not illuminated on the power adapter check the fuse by 3) With the supplied hex wrench, loosen the hex screw until the jack starts to simply unscrewing the metal cap located on the end of the power adapter.
- Page 5 TROUBLE SHOOTING CUSTOMER SERVICE For customer support please visit Deltran-Global.com/Hyperion. You can also PROBLEM POSSIBLE CAUSE SOLUTION call our customer service hotline 877-456-7901 Electric jack does The switches are set in the Set switches to correct position not have power...
