2 SEATER SWING HAMMOCK
Assembly Instructions
Dimensions
Width - 151 cm
Depth - 113 cm
Height - 154 cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6400800
- Please keep for future referenc e
450/4272
ISTR.675 - 09/12/15
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Argos 450/4272
- Page 1 Width - 151 cm Depth - 113 cm Height - 154 cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 6400800 ISTR.675 - 09/12/15...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • During assembly do not stand • T o reduce components and tools listed on or put weight on the product, the likelihood of the following pages.
- Page 3 Components - Panels Customer Helpline: Argos = 0345 6400800 Please check you have all the components listed below Back leg x 2 Front leg x 2 Top x 1 (137.5x4.5 cm) (150x34 cm) (178 x 35 cm) Roof bar x 2...
- Page 4 Components - Fittings Please check you have all the fi ttings listed belo w Note: The quantities below are the correct amount to complete the assembly. In some cases more fi ttings may be supplied than are required. M8 x 10cm Screw x 6 M6 x 8cm Screw x 4 M6 x 6cm Screw x 8 M6 x 5,5cm Screw x 4...
- Page 5 Components - Fittings Please check you have all the fi ttings listed belo w Note: The quantities below are the correct amount to complete the assembly. In some cases more fi ttings may be supplied than are required. M8 Nut x 6 M6 Nut x 22 M6 Nut x 2 Ø8 x 12...
- Page 6 Assembly Instructions Step 1 Insert the plastic foot Q onto the end of the back legs 1 Step 2 a: Insert the plastic cap P into the end of front legs 2 Note: Pay attention to the position of the holes b: Insert the plastic foot Q onto the other end of the front legs 2...
- Page 7 Assembly Instructions Step 3 Assemble back leg 1 and front leg 2 together with plastic spacer O using screws A , washers K and nuts H . Note: Do not fully tighten bolts. Repeat with the remaining legs. Step 4 Assemble the top 3 with the legs using screws A , washers K and nuts H .
- Page 8 Assembly Instructions Step 5 fix the plastic caps S onto the side bar 9 Step 6 Assemble the side bar 9 with the legs using screws D , washers L and nuts I. Note: Pay attention to the position of the holes Step 7 Insert the plastic caps V into the end of one...
- Page 9 Assembly Instructions Step 8 Assemble the cross bar 10 with the back legs using screws B, washers L and nuts I Note: Do not fully tighten bolts. Step 9 Insert the plastic caps V into the end of the other cross bar 10 Step 10 Assemble the cross bar...
- Page 10 Assembly Instructions Step 11 Insert the plastic caps V into the end of the armrests 7 Step 12 Assemble the two seat support 6 together using screws D , washers L and nuts I Step 13 Assemble the left armrest with the seat support using screws E , washers L and nuts I...
- Page 11 Assembly Instructions Step 14 Assemble the right armrest 7 with the seat support 6 using screws E , washers L and nuts Step 15 Fix the plastic caps T onto the seat support bar Step 16 Assemble the left back seat support bar 8 to the seat support 6 using screw F , washers L...
- Page 12 Assembly Instructions Step 17 Assemble the right back seat support bar 8 to the seat support 6 using screw F , washers L and nuts I Step 18 Assemble the left front seat support bar 8 to the armrest 7 using screw F , washers L and nuts I Step 19...
- Page 13 Assembly Instructions Step 20 Insert the springs N into the seat support bars 8 Step 21 Fix the spring N to the top 3 Step 22 Fix the nuts J to the pin G , deep in the longest thread.
- Page 14 Assembly Instructions Step 23 Insert the pin G through the plastic joint R by the shortest thread. Push it as far as the nut J touches the plastic joint R Step 24 Fix the plastic joint R to the top 3 using the washer L and the nut Note: the longest thread of...
- Page 15 Assembly Instructions Step 26 Insert the roof poles 5 into the canopy's slots 6 11 Note: Let the roof poles pass through the complete slots Step 27 Insert the roof poles 5 into the assembled roof bar 4 Step 28 Insert the roof poles 5 into the other roof bar 4...
- Page 16 Assembly Instructions Step 29 Fix the other roof bar 4 to the pin G using the washer M and the wheel Tighten completely all bolts. Assembly is complete.
