Summary of Contents for Clearwater Enviro Technologies MineralPURE SPA-1R
- Page 1 ® INSTALLATION & SPA CARE MANUAL MODEL SPA-1R - Outdoor Unit - FOR ALL SPAS UP TO 2,000 GALLONS Phone: 727-562-5186 • www.clearwater-enviro.com ООО "Бассейн-Сервис" – продажа и монтаж оборудования для бассейнов. Тел: 8 (800) 700-65-50, www.bassein-servis.ru...
- Page 2 FIRST, BALANCE THE SPA'S WATER Before installing the SPA-1R Clearwater Spa Purifier, the spas water must be clear and balanced properly. It is extremely important that the following guidelines are implemented - so please read thoroughly. PREVIOUS SANITIZER USE If the previous sanitizer used was Baquacil, you will need to remove every drop of it, as Baquacil is not compatible with any other sanitizer including the Clearwater Spa Purifier.
- Page 3 TOTAL ALKALINITY TEST MONTHLY AND MAINTAIN BETWEEN 80-120 PPM Using a normal Total Alkalinity test kit, determine the reading and adjust. IF THE TOTAL ALKALINITY IS UNDER 80 PPM Raise the Total Alkalinity to about 100 ppm by adding sodium bicarbonate (baking soda). Consult chart on amount needed. IF THE TOTAL ALKALINITY IS OVER 120 PPM Lower the Total Alkalinity to about 100 ppm by adding muriatic acid or dry acid.
- Page 4 You can very easily raise the TDS level - IF YOU NEED TO. Remember, the TDS level always goes up whenever anything is added to the spa, and a reading at least 500 ppm may be obtained over a short period of time. The TDS level never goes down, so if you have to raise the TDS, it would be only for this one time or whenever you change the water in the spa.
- Page 5 INSTALLATION PROCEDURES TOOLS AND MATERIALS REQUIRED Channel lock wrench Hacksaw or backsaw Screws & anchors Utility knife Crescent Wrench Teflon tape Flexible conduit Hammer Screwdriver PVC cleaner/primer 1/2" straight conduit connector Voltage Meter Drill & Drill Bit PVC cement wire stripper COMPONENTS OF THE SPA-1R IONIZER Spa Unit Control Box 1 1/2"...
- Page 6 CHOOSING THE POWER SOURCE When locating the power source, it should be one that turns on and off as the pump and motor does. The best location is the spa's timer box. If no timer box exists, you unit can use the pump motor as its power source by removing the back plate. CONNECTING TO THE TIMER BOX 220 VAC - Connect the black (3 stranded) wire cable to the 220 VAC timer box by splicing the 3 wires and connecting the black and white wires to the LOAD side on the timer box.
-
Page 7: Trouble Shooting
IF THE COPPER-ION LEVEL IS TOO LOW Turn the control knob up (or clockwise) a notch. Test the following day. Continue this procedure till the Copper-Ion level stabilizes. Once you obtain the proper setting, this usually stays the same all season long. If the water gets colder, the chance of algae and bacteria decrease, thus a lower Copper-Ion level may be required. - Page 8 If the fuse was NOT BLOWN, and you get no output at all, check back of circuit board for anything unusual - loose parts, burn marks, etc. If this is the case, return the CIRCUIT BOARD ONLY to your dealer or return to Clearwater Enviro Tech, prepaid postage.
