- Page 1 OnQ Technologies Manual 1307541-02 Rev. O - 10/25/02 8-Port Ethernet 10/100Mbps Network Switch Part No. 364411-02 - 1 -...
- Page 2 Description: The 8-Port 10/100 Network Switch, Part No. 364411-02 provides a flexible, reliable and affordable solution for an Ethernet network. It comes with eight independent 10BASE-T /100BASE-TX ports. Each port delivers up to 200Mbps throughput and is able to operate in either half or full-duplex modes.
-
Page 3: Power Port
OnQ Technologies Manual 1307541-02 Rev. O - 10/25/02 PARTS NAMES AND FUNCTIONS Front Panel LED Indications Status Description POWER Power On A valid connection LINK/ACT Blinks Receives packets Connects to a 100Mbps Fast Ethernet connection Connects 10Mbps Ethernet connection Ethernet Ports (1-8) Ethernet Ports with MDI/MDIX auto crossover capacity.
