Sole Plate
1
Cut Guide
2
Angle Lock
3
Angle Scale
4
Rip Guide Lock
5
Front Handle
6
Rating Plate
7
Motor Vents
8
Depth Lock
9
Spring Loaded
10
Blade Shield
Saw Blade
11
Blade Locking Washer
12
and Screw
Blade Shield Retractor
13
UniGrip Release Slider
14
Table Saw Shield Catch
15
Dust Extractor Fitting
16
UniGrip(Sold Separately)
17
Table Saw Blade Shield
18
(Sold Separately)
Battery (sold separately)
19
CS05
1
2
3
4
5
6
8
7
9
19
Circular Saw
10
11
12
13
15
16
18
14
17
Advertisement
Table of Contents
Summary of Contents for CEL Power8 CS05
- Page 1 CS05 Circular Saw Sole Plate Cut Guide Angle Lock Angle Scale Rip Guide Lock Front Handle Rating Plate Motor Vents Depth Lock Spring Loaded Blade Shield Saw Blade Blade Locking Washer and Screw Blade Shield Retractor UniGrip Release Slider Table Saw Shield Catch Dust Extractor Fitting UniGrip(Sold Separately) Table Saw Blade Shield...
- Page 2 If you experience any problems with the product please contact Kickback could cause the saw to jump backwards, but kickback forces can email: power8@cel-global.com be controlled by the operator, if proper precautions are taken. www.cel-global.com...
- Page 3 PREPARE YOUR WORK • Mark your cut and use the notch at the front of • When cutting thick timber or performing compound or angled the Sole Plate to guide the blade. cuts it may be necessary to rotate the blade shield to prevent it stopping the cut as it hooks on the edge of the work piece.
- Page 4 INTENDED USE FITTING UNIGRIP AND BATTERY The machine is intended for lengthways and crossways cutting Inserting the UniGrip of wood with straight cutting lines as well as mitre cuts in wood Align the rails on the UNIGRIP Circular Saw so they will slide while resting firmly on the work piece or correctly mounted in smoothly into the rails on the UniGrip.
- Page 5 OPERATING THE TOOL Change Blade Depth Always remove the battery before Rotate the Depth Lock clockwise to unlock. Set the blade to the cleaning or making adjustments to required depth. Rotate the Depth Lock anti-clockwise so it firmly the tool or attachments. locks the sole plate.
- Page 6 ASSEMBLE A TABLE SAW CARE AND ENVIRONMENT General inspection Fit the Circular Saw to the These instructions should be read in Regularly check that all the fixing screws are present and tight, Case Lid conjunction with those for the specific they may vibrate loose over time.
