FLEXBAR MACHINE CORPORATION
MILLING MACHINE VISOR GUARD KIT
INSTALLATION INSTRUCTIONS
Install Machine Arm on the horizontal area behind the motor
drive head.
There are several methods of installation depending on your
machine.
1. Use the 3/4", 5/8" or 19mm threaded lifting hole if avail-
able
5/8" reducer washer supplied
Tighten the 3/8" bolts 2X to stabilize the arm
This kit is set up for left side installation
For right side installation reverse flexarm to shield mount
2. Drill & tap 3/8" -24 holes 2X. Use the Machine Arm as a
drill template
3. Use the 1/2" holes 2X and drill & tap custom mounting
holes
4. For machines with a Digital Readout mounted in the
lifting hole use the Readout spacer
MODEL #13460
250 GIBBS ROAD • ISLANDIA, NY 11749
800-879-7575 • FAX 631-582-8487
www.flexbar.com
- 1 -
Advertisement
Table of Contents
Summary of Contents for flexbar 13460
- Page 1 FLEXBAR MACHINE CORPORATION MODEL #13460 MILLING MACHINE VISOR GUARD KIT INSTALLATION INSTRUCTIONS Install Machine Arm on the horizontal area behind the motor drive head. There are several methods of installation depending on your machine. 1. Use the 3/4”, 5/8” or 19mm threaded lifting hole if avail- able 5/8”...
- Page 2 Install the Horizontal Tube into tube mount and lock 1. The tube mount can be adjusted left or right 2. The Horizontal Tube can be adjusted front to back 3. The Vertical angle should be in the vertical downward posi- tion Install the Flexarm/Shield to the Vertical Angle 1.
