GVD M1121 Quick Start Manual

Mobile nvr
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
GVD
Mobile NVR M1121
Quick Start Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M1121 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GVD M1121

Summary of Contents for GVD M1121

  • Page 1 Mobile NVR M1121 Quick Start Guide...

  • Page 3: Table Of Contents

    Open Cutout Door ............11 Network for the 1st Time..........46 Install SATA HDD/SSD ............12 Install a WiFi Module ............14 Install a 3G or 4G plus GPS Module (Optional) ....17 Install a SIM Card ............20 Mobile NVR M1121 Quick Start Guide...

  • Page 4: Preface

    If you are not sure about the description herein, consult your vendor before further handling. We recommend that you keep one copy of this document for the quick reference for any necessary maintenance in the future. Thank you for choosing GVD products. Declaration of Conformity This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.

  • Page 5: Hardware Requirements

    Recording data is one of the most important parts for video surveillance, and hard disk drives are one of the most important components to safely store the recording data. It is always recommended that you use the hard disk drives certified by GVD. Find the list of the GVD- certified hard disk drives at the link below: http://www.gvdigital.com/gvdweb/html/document/Support_Lists/Certified%20HDD%20List.pdf...
  • Page 6 Mobile NVR M1121 Quick Start Guide...

  • Page 7: Introduction

    Thank you for choosing GVD products. The M1121 is the light-weight solution of GVD's brand new mobile NVR line, M1 Series. Powered by Intel® Atom™ Bay Trail E3845 Quad-core, M1121 is a fanless NVR to deliver appropriate CPU calculation with low power consumption. The ®...

  • Page 8: Accessories

    A few screws to fix the module ■ stainless-steel round philips screws ■ 1 wall-mount bracket Wall-mount Kit ■ 8 x rubber bumpers ■ 8 x M4 screws Power Adapter 24V/6.67A 160W AC/DC adapter (Optional) (for +8~35VDC output) Mobile NVR M1121 Quick Start Guide...
  • Page 9 All regions (Optional) Sierra Wireless® AirPrime™ MC8705 w/ 15cm internal wire A few screws to fix the ■ Operational bands: WCDMA 850, module WCDMA 900, WCDMA 1900, WCDMA 2100 ■ Stainless-steel round philips screws Mobile NVR M1121 Quick Start Guide...

  • Page 10: Take A Tour

    One USB 3.0 port that runs with xHCI (eXtensible Host Control Interface) by default and supports the USB 3.0 port devices of USB 3.0, USB 2.0, USB 1.1 and USB 1.0. Legacy USB is only supported when the xHCI is set to Smart Auto in the BIOS Setup utility. Mobile NVR M1121 Quick Start Guide...
  • Page 11 DC-in power A wide range of power input from +8 to +35 V including the prevalent 12V and 24V vehicle power system. jack See also DC-in Power Jack on page for the pin definition. Mobile NVR M1121 Quick Start Guide...

  • Page 12: Rear Panel

    Supports CAN2.0A and CAN2.0B up to 1 Mbps. See also CAN bus connector on page for the pin definition. Antenna cutout hole A cutout hole for an antenna-wired SMA connector to join an external antenna. Mobile NVR M1121 Quick Start Guide...

  • Page 13: Side Panel

    SMA connector to go through to join an external antenna. See also Install a WiFi Antenna cutout holes Module on page Install a 3G or 4G plus GPS Module (Optional) on page more details. Mobile NVR M1121 Quick Start Guide...

  • Page 14: Motherboard

    2 USB-only CAN bus Mini PCIe connector socket Half-size mSATA connector SATA power receptacle USB 3.0 USB 2.0 3-pin DB-15 DDR3L COM1 COM2 ports ports DC-in video SO-DIMM ports power jack connector socket Mobile NVR M1121 Quick Start Guide...
  • Page 15 DC power in from 8V to 35V. Connector: 3-pin terminal block Pinout: Def. Description Positive polarity of DC power input from 8V~35V. GND Negative polarity of DC power input Ignition input for ignition power control Mobile NVR M1121 Quick Start Guide...
  • Page 16 CAN_L Yes CAN bus low-level voltage 6 Reserved No Reserved pin. Keeps unconnected. 7 Reserved No Reserved pin. Keeps unconnected. 8 Reserved No Reserved pin. Keeps unconnected. 9 Reserved No Reserved pin. Keeps unconnected. Mobile NVR M1121 Quick Start Guide...

  • Page 17: Install Hardware

    NVR. Part the cutout door from the mobile NVR. The inside of the mobile NVR then comes to view. Part the cutout door from the mobile NVR. Mobile NVR M1121 Quick Start Guide...

  • Page 18: Install Sata Hdd/Ssd

    Open the cutout door at the bottom. Install a SATA HDD or SSD onto the cutout Pull the SATA cable connector from the door by fastening 4 screws. motherboard. Find the SATA cable connector on the motherboard. Mobile NVR M1121 Quick Start Guide...
  • Page 19 Install SATA HDD/SSD Connect the SATA HDD/SSD. Connect the SATA HDD/SSD with the onboard SATA cable. Restore the cutout door. Restore the cutout door by fastening the 3 screws. Mobile NVR M1121 Quick Start Guide...

  • Page 20: Install A Wifi Module

    Mini Card socket, accessories. extend the WiFi module with The module a “mini half bracket”. Join is a half-size them together by using two module of PCIe Mini Card, screws. with two U.FL connectors. Mobile NVR M1121 Quick Start Guide...
  • Page 21 Then completely remove the bottom cover from the mobile NVR. First remove these screws. Open this hole for the WiFi antenna. Then dismantle the whole bottom cover. Mobile NVR M1121 Quick Start Guide...
  • Page 22 12. Restore the cutout door to the mobile NVR. 14. Proceed to install WiFi device driver as described in Appendix. Install WiFi Device Driver & Connect WiFi Network for the 1st Time on page 46. Mobile NVR M1121 Quick Start Guide...

  • Page 23: Install A 3G Or 4G Plus Gps Module (Optional)

    Have the 3G or 4G plus GPS module from the accessories. Connect the module to the connector by a slanted angle. Note the notch on the module should meet the break on the connector. Mobile NVR M1121 Quick Start Guide...
  • Page 24 Arrange the flat side of the SMA connector to meet the flat side of Open two holes the antenna hole. for 3G or 4G and GPS antennas. Mobile NVR M1121 Quick Start Guide...
  • Page 25 3G or 4G WiFi WiFi 13. Proceed to install a SIM card as described Install a SIM Card on page 20. Mobile NVR M1121 Quick Start Guide...

  • Page 26: Install A Sim Card

    Power off the mobile NVR. From the side panel, find the outside-accessible Note To remove the SIM card, simply SIM card slot, which is a push-push type. push-eject the card. Outside- accessible SIM card slot Mobile NVR M1121 Quick Start Guide...
  • Page 27 To install an internal SIM card: Power off the mobile NVR. Open the mobile NVR and access the motherboard as described in Open Cutout Door on page 11. The motherboard then comes to view. Mobile NVR M1121 Quick Start Guide...
  • Page 28 Appendix. Install 3G/4G Device Driver & Connect Mobile Network for the 1st Time on page 43. Put down the hinged cover and push it forth to lcok the SIM card in place. Mobile NVR M1121 Quick Start Guide...

  • Page 29: Mount The Mobile Nvr

    Place the mobile NVR upside down on a flat and soft surface. Remove the four rubber feet that are sticked to the bottom of the mobile NVR as marked in the illustration below. Remove the four rubber feet. Mobile NVR M1121 Quick Start Guide...
  • Page 30 Fasten 4 screws to fix the metal bracket to the bottom of the mobile NVR. Mount the other four rubber bumpers onto the metal bracket. Mount the other four rubber bumpers onto the metal bracket. Mobile NVR M1121 Quick Start Guide...

  • Page 31: Wire Dc-In Power Source

    Only the insulated parts of the wires should extend from the terminal block plugs. Note the polarities between the wires and the terminal block plugs must be Mobile NVR M1121 Quick Start Guide...
  • Page 32 ➎ Note If the mobile NVR is used on a train, it is recommended that you use an additional EN50155-compliant single-output DC-to-DC converter or let the mobile NVR tap from UPS (uninterruptible power supply). Mobile NVR M1121 Quick Start Guide...

  • Page 33: Manage Ignition Power

    Connect ACC line to IGN. Caution 1. Make sure your DC power source and IGN signal share the same ground 2. The IGN input accepts max. 35VDC. Supplying power over 35VDC may damage the system. Mobile NVR M1121 Quick Start Guide...

  • Page 34: Select Ignition Power Mode

    "smart off-delay", which auto-detects Power-off delay 2 hr. system status during the power-off delay to cut Hard-off timeout 10 min. off the system power if the system powers off before the power-off delay expires. Mobile NVR M1121 Quick Start Guide...

  • Page 35: Set Up Windows

    It takes a while for the wizard to finalize the your locale. settings. ➌ ➍ Once the finalization is through, the system auto- Click the Next button to proceed. restarts to apply the change. Mobile NVR M1121 Quick Start Guide...

  • Page 36: Initialize Hdds

    When the initialization is through, the selected HDDs will display “Online” status. Note For HDD size greater than 2TB, select GPT instead of MBR for initialization. Right-click on a “Non Initialized” HDDs and then click Initialize Disk. Mobile NVR M1121 Quick Start Guide...

  • Page 37: Launch & Log In

    Initialize HDDs on page 30, proceed to launch and log in to GVD HD NVR, a collection of utilities that allow the mobile NVR to control of all the networked cameras. Follow the guide below to launch the HD NVR Manager for the first time: The software then prompts you to confirm.

  • Page 38: Use Installation Wizard

    Name. The Initialize Wizard auto-opens. 3. Enter a desired name for the NVR. Then click The welcome page of the Initialization Wizard. the Next button to proceed. 2. Click the Next button to continue. Mobile NVR M1121 Quick Start Guide...
  • Page 39 Then click the From the Date and Time window that opens, Next button to proceed. click the Change time zone... button and set the time zone. Then click the Next button to proceed. Mobile NVR M1121 Quick Start Guide...
  • Page 40 Yes to proceed. Then click the Next button to proceed. 9. Log in to the NVR again. After login, the wizard reopens Step 5: Network Setting. 10. Click the Next button again to proceed. Mobile NVR M1121 Quick Start Guide...
  • Page 41 If after the rescanning manufacturer's default username & the cameras to discover still cannot be password to add a camera. discovered, click the button to open the Manually Add Camera tool. Mobile NVR M1121 Quick Start Guide...
  • Page 42 15. Select the camera(s) to enable recording for. Then click the Next button to proceed. The wizard then prompts Step 9: Storage 14. Select the camera(s) you want to import. Automation Declaration. Then click the Next button to proceed. Mobile NVR M1121 Quick Start Guide...
  • Page 43 (a). If you have selected Yes in step 16, follow The HD NVR Manager then launches. the guide below to proceed. (1) Click the Execute button. Mobile NVR M1121 Quick Start Guide...
  • Page 44 (2) Click the OK button to close the prompt. (3) Back to the wizard, click the Finish button to finish the configuration and quit the wizard. Mobile NVR M1121 Quick Start Guide...

  • Page 45: Configure Network Parameters

    Sharing Center | Change adapter press the OK button. settings. Right-click over the active connection to use and click Properties from the context menu that opens. Click Internet Protocol Version 4 (TCP/IPv4). Then click the Properties button. Mobile NVR M1121 Quick Start Guide...

  • Page 46: Create Storage Volumes

    A New Volume dialog box then opens. A prompt then shows and asks for your 5. In the Volume Name field, enter the name confirmation. of the volume to create. 9. Click Yes to continue. Mobile NVR M1121 Quick Start Guide...

  • Page 47: Auto-Add A Camera

    See the user’s manual to know how to the Device tab from the Tree Panel. Then "manually-add" a camera. click the plus sign button Click An Auto Discovery window then opens. Tree Panel Then click. Mobile NVR M1121 Quick Start Guide...
  • Page 48 11. Click the OK button to finish and quit the 8. To enable the camera to record videos, click the setting. Recording Settings tab on the Configuration Page. Note To set up the schedule recording, see the user’s manual for details. ➑ ➒ Mobile NVR M1121 Quick Start Guide...

  • Page 49: Appendix. Install 3G/4G Device Driver & Connect Mobile Network For The 1St Time

    3G or 4G device driver on Sierra Wireless website or HUAWEI website. The installer then opens. Click the I Agree button to proceed. The driver installation then starts, progresses and finishes. Mobile NVR M1121 Quick Start Guide When the installation is through, the wizard...
  • Page 50 Click the mobile network you want to use and of the operating system shows an icon then click the Connect button. saying Unidentified network and No Double-click the mobile network you want network access. to use. Mobile NVR M1121 Quick Start Guide...
  • Page 51 If you are asked for a PIN code, enter the vaild code. The Notfication Area then shows an icon that signifies the signal strength. The mobile network to connect is connected. Mobile network is connected. Mobile NVR M1121 Quick Start Guide...

  • Page 52: Appendix. Install Wifi Device Driver & Connect Wifi Network For The 1St Time

    Utility or simply Install driver only. Then click the Next button to proceed. Note Since the operating system, Windows 7 Embeded, comes with a WiFi connection utility, it isn't a must to install the connection utility featured by the module. Mobile NVR M1121 Quick Start Guide...
  • Page 53 WiFi network. Then click the icon The Netowrk and sharing center then opens and shows the available WiFi network(s) within reach. When the installation is through, the wizard prompts having succesfully installed the driver. Mobile NVR M1121 Quick Start Guide...
  • Page 54 The utility then opens a Connect to a Network dialog box and tries to connect the WiFi network you clicked. The utility then asks you for the password to access the network. A WiFi network is connected. Mobile NVR M1121 Quick Start Guide...
  • Page 55 May 2016 Genius Vision Digital sales@gvdigital.com support@gvdigital.com www.gvdigital.com...
