ZyAura ZG1683RUD Operating Instructions

ZG1683RUD 3 IN 1 CO2 Monitor (CO
Product Overview
Thank you for selecting ZG1683RUD
measuring the CO concentration ,ambient temperature and the relative humidity (CO2+Temp. +RH),
2
Micro SD card. This product is developed to detect the presence of CO
ZG1683RUD can be widely used in the office building, school, exhibition hall, shopping mall, meeting room, fitness center, restaurant and other
public places where personal comfort, healthy is important.
Features:
□ V Three different LED display shows the current Indoor Air Quality
□ V Press MUTE button for alarm on/off.
□ V Built in the LCD Backlight for easy reading in the dark.
□ V Replace Micro SD card to log the CO2/Temp/RH ,with RTC (Real Time Clock).
more than 10years log capacity .
□ V User can download the PC software to check the CO2/Temp/RH history.
Warnings:
□ V Please take off the AC power adapter and store it well when this CO2 monitor left idle for long.
□ V This CO2 monitor is for home use, not suitable for certifying the test results.
□ V If use this CO2 monitor for testing, ZG1683RUD does not guarantee the test results.
EMC/RFI
Readings may be affected if the unit is operated within radio frequency electromagnetic field strength of approximately 3 volts per meter, but the
performance of the instrument will not be permanently affected.
Note: Under the electromagnetic field of 3V/m, the reading will not meet the specification.
Warm-Up Time: 2 MIN.
1. 2 min. warm-up time when first time power.
2. The LCD shows 4 bars with 1sec blank cycle during warm-up
3. The MUTE button is disabled during warm-up
4. The device shows the CO2 reading after warm-up
Using the MUTE function:
Press MUTE button to select buzzer on/off. If the "MUTE" function is off, while CO2 concentration exceed the alarm level (>1200 ppm), there will be a buzzer.
Note: The device setting with alarm is buzzer on when power on first time, user can set the alarm on/off under MUTE function.
How to log CO2/Temp/RH data?
Method1: this method need PC connection always
Connect to PC with data log function:
1. The ZG1683RUD connect with PC first.
2. http://www.zyaura.com/products/ZG1683R.asp
(ZyAura_USB_HUB_PC_software.rar) and installation processes.
+Temp.+RH) Operating Instructions
2
desktop CO monitor, ZG1683RUD CO
2
"Connect to PC with data log function (ZG1683RUD )" for the software
monitor is smart, compact and easy-to-use. In addition to
2
in ambient air and help people to take care of Indoor Air Quality.
2
1. Green LED Display (<800ppm)
2. Yellow LED Display (800-1200ppm)
3. Red LED Display (>1200ppm)
4. Mute Button
5. Power Inlet (Mini USB Socket)
6. Micro SD Card
7. Housing Stand
8. Screw
ZG1683RUD can log these data into
Position
