Power supply PS75
with integrated splitbox
functional description
Fabrication and Marketing
Licht-Technik
Hagenbach & Grill
Osterwaldstr. 9-10 80805 München
Tel. +49(0)89-360528-0 Fax +49(0)89-360528-30
E-mail: INFO@LICHT-TECHNIK.COM
Last updated on: 19/06/18 Rev.: 1.02
Power supply PS75-04 Rev.: 1.02
1
Advertisement
Table of Contents
Summary of Contents for Licht-Technik PS75-04
- Page 1 Power supply PS75 with integrated splitbox functional description Fabrication and Marketing Licht-Technik Hagenbach & Grill Osterwaldstr. 9-10 80805 München Tel. +49(0)89-360528-0 Fax +49(0)89-360528-30 E-mail: INFO@LICHT-TECHNIK.COM Last updated on: 19/06/18 Rev.: 1.02 Power supply PS75-04 Rev.: 1.02...
- Page 2 Caution! Operate the device only after having read and understood operating instructions! Power supply PS75 Rev.: 1.02...
-
Page 3: Power Supply Ps75
Power supply PS75 Power supplies with integrated DMX-splitbox for Licht-Technik color changer, dimmer shutter and motorized yokes. The PS75 can have a maximum load of one motoryoke with stargate (four leaf barndoor with rotation), focus, mechanical dimmer shutter and color changer unit. -
Page 4: Table Of Contents
Table of content Power supply PS75......................3 Safety and operating instructions..................5 Cabling..........................6 Getting started........................7 Technical data........................8 Malfunctions......................... 9 Warranty..........................10 Further information......................10 EC Declaration of Conformity..................... 11 Power supply PS75 Rev.: 1.02... -
Page 5: Safety And Operating Instructions
Prior to starting the equipment the user must check the usefulness of the device for its intended purpose. In particular, Licht-Technik shall decline any liability for damages of the equipment as well as for consequential damages resulting of the device being used inappropriately, of inexpert installation, incorrect starting and use, and of non-compliance with the valid safety regulations. -
Page 6: Cabling
Also without power! DMX 4pin XLR DataPower line Licht-Technik devices DMX512/1990 panel The standardized DMX-Signal is based on industrie´s RS485 Interface. It is designed for maximum lengths up to 1200m. This length is under condition in theatre or studio normally not possible. -
Page 7: Getting Started
Connect further DMX receiver or further splitboxes to DMX out (5pin) – At the 4pin outputs devices like color changer, shutter or motoryoke are connected – Switch on the power supply at the main switch – Power supply PS75-04 Rev.: 1.02... -
Page 8: Technical Data
Technical data Dimensions and Weight: PS75-04: (LxWXD): 240mm x 140mm x 70mm 1,6 kg Mains voltage: 85..132 V AC or 187..264 V AC Admissible ambient temperature: 0..40 degree Celsius Maximum output power: 7,5A, 180VA Output voltage: 28 V DC Fuse(s):... -
Page 9: Malfunctions
Caution! Before opening the housing disconnect the device from electrical mains Caution! Change the fuse only in disconnected condition. If the fuse will blow again, the device has to be repaired at Licht-Technik Caution! Replace a defect fuse only with a fuse of the right value... -
Page 10: Warranty
All maintenance and servicing works related to the product must be carried out by the company Licht-Technik. Licht-Technik shall not assume any liability for losses or damages of any kind being the results of inexpert servicing. Further information... -
Page 11: Ec Declaration Of Conformity
Not applicable This declaration is invalid if the device is changed techically and/or unintended use. Signed for Licht-Technik Vertriebs GmbH Place and date of description München 6.9.2017 ---------------------------------------------- -------------------------------------------- Uwe Hagenbach (Geschäftsführer) Bernhard Grill (Geschäftsführer) Power supply PS75-04 Rev.: 1.02...
