Mollii Jacket User Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

User Manual

ENGLISH

WARNING

Read and understand

operator's manual

and all other safety

instructions before using

this equipment.

This user manual (version 1.6 EN) was produced by Inerventions and

applies to Mollii. The operating instructions are valid from xx-xx-2019.

Firmware version: 1.3x

Inerventions AB, Svärdvägen 11D, SE-182 33 Danderyd

Tel: +46 (0)8 410 277 01

Table of Contents

Need help?

Do you have a question about the Jacket and is the answer not in the manual?

Questions and answers

Summary of Contents for Mollii Jacket

Page 1 This user manual (version 1.6 EN) was produced by Inerventions and applies to Mollii. The operating instructions are valid from xx-xx-2019. Firmware version: 1.3x Inerventions AB, Svärdvägen 11D, SE-182 33 Danderyd Tel: +46 (0)8 410 277 01...
Page 3: Table Of Contents
TABLE OF CONTENT 1. Eight step instruction on how to use Mollii STEP 1: Read the intended use and safety instructions carefully STEP 2: Check that the set is complete STEP 3: Insert batteries STEP 4: Dressing up STEP 5: Install the control unit...
Page 4 1. EIGHT-STEP INSTRUCTION ON HOW TO USE MOLLII...
Page 5: Step 1: Read The Intended Use And Safety Instructions Carefully
- Together with electronic life-support equipment or high-frequency operation equipment -Together with ECG-equipment. There is a risk of Mollii disturbing the function of the above-mentioned types of equipment . All incorrect usage is at the user’s own risk. WARNINGS Do not modify Mollii without authorization of the manufacturer.
Page 6 Always consult a doctor. Mollii is for use solely by the user for whom it is adapted. Mollii may only be used by, or under the supervision of, a person who has read and understood the entire user manual.
Page 7 - To moisturise the skin frequently with unscented skin lotion. Avoid using Mollii when your skin is dry. - To never use Mollii if there are sores on the skin or if it is irritated or injured. ACCIDENTS, INJURIES OR INCIDENTS...
Page 8: Step 2: Check That The Set Is Complete
STEP CHECK THAT THE SET IS COMPLETE Mollii jacket* Mollii control unit sup- plied with a belt* Mollii trousers* Laundry bag x2 Protective box for the control unit * Note: Jacket, trousers and control unit have unique item numbers.
Page 9: Step 3: Insert Batteries
Do not use carbon-zinc AAA batteries as they do not last very long and they may leak acid into the Mollii device. OPEN BATTERY COVER Place the control unit with the screen facing down. Pull the belt away to uncover the battery hatch.
Page 10: Step 4: Dressing Up
CLOSE BATTERY COVER Check that no screws or external items have been left behind before replacing the battery cover in the directions indicated in the battery socket. Screw the cover on firmly using a screwdriver. CHECK THE BATTERY LEVEL Turn the control unit on by pressing the ON button. Check the battery level: Battery full Battery half full Battery low.
Page 11 OPEN ALL THE TROUSERS’ ZIPPERS BEFORE DRESSING UP PUT THE TROUSERS ON ADJUST THE KNEE-CAP PLACEMENT Ensure that the seam is above the knee. CLOSE THE TROUSERS’ ZIPPERS CHECK THAT THE ELECTRODES ARE IN CONTACT WITH THE SKIN...
Page 12 OPEN ALL THE JACKET’S ZIPPERS PUT THE JACKET ON ENSURE THE JACKET IS OVER THE PANTS The jacket should be outside the trousers. Snap the jacket to the trousers with the buttons. CLOSE THE JACKET’S ZIPPERS ADJUST THE FOREARMS PLACEMENT...
Page 13: Step 5: Install The Control Unit
STEP INSTALL THE CONTROL UNIT POSITION THE CONTROL UNIT Place the control unit on the belly above the hipline and below the waistline with the display facing away from the belly as indicated below: CLICK THE BELT AROUND THE WAIST Click the belt on by vertically sliding the two parts together.
Page 14 RECHECK THAT THE CONTROL UNIT IS ON Recheck that the control unit is on. If not, press the ON button. CAREFULLY CONNECT THE MAGNETIC ARMS Place the upper left magnetic arm carefully on the upper left connector. If you are experiencing magnetic repulsing, then you are placing the wrong magnetic arm.
Page 15 Correct position: Incorrect positions:...
Page 16: Step 6: Start A 60-Minute Mollii Session
Press PLAY/PAUSE again to continue the session. DURING USE While using Mollii, you can remain still, move around or exercise. Check that each magnetic arm is in the correct postion, when moving around. If not, make sure to reposition it correctly.
Page 17: Step 8: Cleaning Mollii, Storage And Service Life
- Avoid dusty, damp and bright environments. - Store Mollii control unit in the protective box. - Remove all batteries if Mollii is not going to be used for 3 weeks or more. SERVICE LIFE Mollii is garanteed to last for 25 machine washes, or 250 steam cabinet washing, or 2 years of regular use under the condition prescribed herein.
Page 18: Trouble Shooting
2. Trouble Shooting Section Problem Possible causes Solution No display Low batteries Replace batteries Batteries inserted incor- Check instructions in Section rectly 1 STEP 3 Display showing The control unit is unpro- Contact Inerventions AB or the symbol grammed your local reseller Sudden change in Incorrect position of mag- Verify battery level and check...
Page 19: Reporting Faults And Accidents
3. Reporting faults and accidents If an accident, injury or incident occurs, please contact Inerventions AB. Faulty equipment must not be used. Immediately contact: Inerventions AB Svärdvägen 11D 182 33 Danderyd Tel: +46 (0)8 410 277 01 Mail: info@mollii.com...
Page 20: About Electrical Nerve And Muscle Stimulation
• Maximum amplitude: 20 V Each Mollii suit is customized when it is prescribed. Depending on diagnosis and manual examination of the patient, the prescriber decides which muscles are to be stimulated and with which pulse parameter setting. The user cannot change param- eter settings and/or which muscles are to be stimulated.
Page 21: Technical Description
Mollii is a multi-channel full-body suit with a low energy electrical stimulation – 20 Volt and 20 Hz. It is composed of a control unit, a jacket and a trouser, with 58 em- bedded electrodes, in direct contact with the skin, and pre-positioned to stimulate 40 key muscle groups.
Page 22 6. Table Data and Standars Mollii is CE-labelled as a medical device, and thereby complies with the directive concerning medical devices (MDD 93/42/EEC). In order to meet the requirements, Inerventions has voluntarily chosen to fulfil EN ISO 14971 and ISO 14971 Application of risk management to medical...
Page 24: Symbols
Symbol: Patient connection is Symbol: Do not wring out when classified: BF drying Symbol: Read the entire user manual prior to using Mollii Temperature range Quantity...
Page 25 7. Symbols . Device is only for use by Catalog/re-order part number prescription Fragile European Community Repre- sentative Keep dry Serial Number Manufacturer Degree of ingress protection per IEC 60529 Universal Device Identification Altitude/pressure range (UDI) Temperature range .Do not use device if packing is damaged.
Page 26 Inerventions AB, Svärdvägen 11D, SE-182 33 Danderyd. Tel: +46 (0)8 410 277 01...
