Summary of Contents for Adastra ML622
Page 1
ML622 1U RACK MIC/LINE MIXER Item ref: 953.026UK User Manual Version 2.0 Caution: Please read this manual carefully before operating Damage caused by misuse is not covered by the warranty...
Page 2
Introduction Thank you for choosing an Adastra ML mic/line mixer as part of your sound reinforcement system. This unit is designed to offer high quality, dependable service for audio mixing and distribution. Please read this manual to gain the best results from your product and avoid damage through misuse.
Page 3
Front panel Mic/Line inputs 1-6 Level controls Master volume control Aux 1 + Aux 2 Level controls L+R output meters Global Tone controls Power on/off switch and indicator Rear panel Mains inlet IEC and fuse holder Aux 1 + Aux 2 RCA line inputs (L+R) 24Vdc power contacts Mic/Line &...
Page 4
When Mic/Line 1 is silent, other inputs will resume normal volume level. The amount by which this function mutes the other channels is set by a rotary control (15) on the rear panel. Turn down amplifiers or active speakers before powering down the ML622 mixer to avoid loud noises. Specifications...
