Summary of Contents for ProRacing VP
- Page 1 ProRacing Chip Box Digital VP ® Certificate IPC: 7711/21, IEC: 61340-4-1...
-
Page 2: Table Of Contents
Table of Contents. 1. ProRacing® Chip Box Digital VP..............3 2. Set contains...................... 3 3. Principle of operation..................4 4. Pro Power Increase – The Power Boost............4 5. Pro Driving Safety – For your and others’ safety..........4 6. -
Page 3: Proracing® Chip Box Digital Vp
1. ProRacing® Chip Box Digital VP. ProRacing Chip Box Digital VP is a digital device connected in the engine compartment. The device is programmed for use with diesel engines equip- ped with rotary pump VP37 - cars from Volkswagen Group (VAG). Equipped with an additional self-regulation system - rotary potentiometer. -
Page 4: Principle Of Operation
3. Principle of operation. The device is prepared for mounting in the engine compartment, in a suitable sensor at the fuel pump. As a result, we modify the data transmitted between the control computer (ECU) and the corresponding sensor, including fuel injection, fuel charge, turbocharger boost, air feed rate, engine speed, throttle position, injector opening time. -
Page 5: Pro Eco Driving - Fuel Economy
6. Pro Eco Driving – Fuel Economy. 1. Reduce fuel consumption up to 1.5 l per 100 km • Among the defined 10 MAPs are also ECO maps - which limit fuel consumption. We use them mostly for long trips. In a continuous route, without rapid acce- leration and deceleration, we can expect a reduction of up to 1.5 l per 100 km. -
Page 6: Typical Location Of The Plug
Engine protection function. Ensures the engine operates in a safe range of engine speed. The power increase is always maintained within the tolerance range of the engine. This function prevents the engine from overheating at high loads - very dynamic driving. Fast effect. -
Page 8: Installation
9. Installation. The device is prepared for mounting in the engine compartment, to a suitable sensor on the rotary pump. As a result, we modify the data transmitted between the control computer (ECU) and the corresponding sensor, including fuel injection, fuel charge, turbocharger boost, air feed rate, engine speed, throttle position, injector opening time. - Page 9 Step 5. Connect the female plug with the previously unplugged male plug, then connect the cable to the VP Chip Box. Attach the Chip Box in a safe place, away from the hot engine. After correct installation, you can start...
-
Page 10: Installation In Volkswagen T4
Volkswagen Transporter T4. The VP37 pump driver plug is located underneath the engine. To mount the ProRacing® Chip Box Vp-10 Map you must first remove the motor cover. Warning! The cover is mounted on a series of screws. Take particular... -
Page 11: Marking Of The Vag Engines With A Vp37 Pump
Marking of the VAG engines with a VP37 pump. Engine Mark Power Torque 1Z, AHU 1.9TDi 90 hp (66 kW) 202 N•m 1.9TDi AGR, AHH, ALE, 90 hp (66 kW) 210 N•m 1.9TDi AFN, AHF, ASV, 110 hp (80kW) 235 N•m AVG, ASF 2.5 TDi (niebieska AJT, AYY... -
Page 12: Types Of Plugs
Types of plugs. Depending on the car model, the plugs on the VP37 can be 8 - pin or 10 - pin. Below are drawings of male and female plugins, eight and ten-pin. Female plug 8 PIN. Male plug 8 PIN. Female plug 10 PIN. -
Page 13: Faq
Q: Should I turn off the engine before adjusting? A: Yes. In order for the ProRacing® Chip Box VP device to work properly, each time before any adjustment the motor should be turn off. Thanks to this, we are sure that the modification will have a correct effect on the ECU in the car. -
Page 14: Regulation Of The Device
Regulation of the device. You receive a device programmed for your car. Chip Box should not be adjusted immediately after installing! After installing the device, the car should cover a distance of about 100 km (not necessarily in one drive.) The engine has to be heated up and cooled at least once so that ECU can completely read the parameters which are changed by Chip Box. -
Page 15: We Meet The Global Ipc Standards
Check it out and join to our satisfied users! ProRacing® in the world. Our top class devices are sold all over the world! Join our team! -
Page 16: Customer Service
Customer Service. Our service is available to you from Monday to Friday, from 9 to 17 Contact address: Company’s data: ProRacingX ProRacingX Piotr Miziołek Wrocławska 261 Wrocławska 261, 59-220 Legnica, 59-220 Legnica NIP: 511-022-94-10 Poland REGON: 141940372 Technical Support: Sales department: (+48) 506-711-155 (+48) 720-004-003 (+48) 514-186-905...
