Summary of Contents for Clearwater Spas ClearStream Gecko in.stream
- Page 1 TECH BOOK ClearStream Audio System by Gecko ™ ® ClearStream ™ Audio System (in.stream by Gecko ™ ® wireless music streamed into your yard Use Bluetooth wireless technology to ® listen to music in your spa ClearStream manual | 1-13...
-
Page 2: Table Of Contents
in.stream TechBook Table of contents Warnings 2 Introduction 5 Overview 6 Mount on a horizontal or vertical surface 7 Installation of ink113 single switch 7 Installation of ink175 keypad with adhesive 8 Wiring diagram 9 Speakers and supply 9 Connecting the keypad to instream 10 Wireless set-up 11 Basic operation/ink175 12 Basic operation/ink113 13 Specifications ... -
Page 3: Warnings
in.stream TechBook Warnings WARNINGS: Before installing or connecting the unit, please read the following DO NOT DISASSEMBLE OR ALTER. Doing so may result in an accident, fire or electrical shock USE THE CORRECT AMPERE RATING WHEN REPLACING FUSES Failure to do so may result in fire or electrical shock DO NOT BLOCK RADIATOR PANEL Doing so may cause heat to build up inside and may result in fire DO NOT PLACE HANDS OR FINGERS ON RADIATOR PANEL Doing so may result in personal injury DO NOT USE FOAM TO ISOLATE THE UNIT Doing so may cause heat to build up inside and may result in fire INSTALL UNIT 1" AWAY FROM OTHER SURFACES Make sure to leave a clearance of at least 1" from other surfaces MAINTENANCE If you have problems, do not attempt to repair the unit yourself Return it to your dealer or service station for servicing ACCESSORY PARTS Be sure to use only the specified accessory parts Use of other than designated parts may damage this unit internally or may not securely install the unit in place This may cause parts to become loose resulting in hazards or product failure DISPOSAL OF THE PRODUCT The appliance (or the product) must be disposed of separately in accordance with the local waste disposal legislation in force WARNINGS: When this equipment is provided as an audio/video component for spas, UL 1563 - 6th edition requires that the following instructions (or equivalent) be provided as part of the ... - Page 4 in.stream TechBook FCC WARNING: This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules These limits are designed to provide reasonable protection against harmful interference in a residential installation This equipment generates, uses and can radiate radio requency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications However, there is no guarantee that interference will not occur in a particular installation If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna Increase the separation between the equipment and receiver Connect the equipment into an outlet on a circuit different from that to which the receiver is connected Consult the dealer or an experienced radio/TV technician for help FCC RF WARNING STATEMENT: The device has been evaluated to meet general RF exposure requirement The device can be used in portable exposure condition without restriction ...
- Page 5 in.stream TechBook RTTE WARNING RTTE Warning (24G) National Restrictions This device is intended for home and office use in all EU countries (and other countries following the EU directive 1999/5/EC) without any limitation except for the countries mentioned below: Country Restriction Reason/remark France Outdoor use limited to 10 mW Military Radiolocation use eirp within the band Refarming of the 24 GHz has been 2454-24835 MHz ongoing in recent years to allow current relaxed regulation Full implementation planned 2012 Italy None For private use, a general authorisation is required if WAS/ RLAN’s are used outside own premises For public use, a general authorisation is required Norway Implemented This subsection does not apply for the geographical area within a radius of 20 km from the centre of Ny-Ålesund Russian Federation None Indoor applications RTTE STATEMENT: Hereby, Gecko Alliance, 450 des Canetons, Quebec City (QC) G2E 5W6 Canada, declares that this Bluetooth device, instream, is in compliance with the essential requirements and other relevant provisions ...
-
Page 6: Introduction
in.stream TechBook Introduction instream Wireless music streamed into your yard! The instream audio system provides the perfect way to bring music to your spa Instream is simple to install and compatible with many audio sources, such as iPods and smart phones equipped with Bluetooth wireless technology The instream design is based on its predecessor, the inchant, and it shares the same sleek enclosure that has been thoroughly used and proven in the spa environment Just pair your device and start playing your favorite music Digital music files or internet radio from your phone will be sent wirelessly to the instream device located under the spa The instream system is equipped with a transceiver and an amplifier to host your speakers Main features Fully waterproof Speaker outputs 40 Watts x 4 ch Auxiliary input Transceiver for Bluetooth wireless technology Accessories In order to use the instream system you must also have either the ink175 keypad or the ink113 single switch Product numbers in.k175 0707-005012: INK175-BK-SPA-AE3 in.k113 0707-008001: INK113-CL-20-AE1... -
Page 7: Overview
in.stream TechBook Overview In.stream dimensions: 675" 7 810" (171 mm) (198 mm) 4210" (107 mm) 25" (64 mm) 0992" (25 mm) 7 650" (194 mm) 825" (210 mm) -
Page 8: Mount On A Horizontal Or Vertical Surface
in.stream TechBook Mount on a horizontal or vertical surface The instream system should be installed on an even Do not install instream in horizontal or vertical surface the upright position as illustrated above Whether horizontal or vertical, this unit should be installed at a location above the flood level of the spa Installation of in.k113 single switch 7/8" 22 mm To install the ink113 single switch, select the most appropriate location for the control switch and drill a 7/8" (22 mm) hole Insert control switch into the hole Tighten the nut to attach firmly (see illustration)... -
Page 9: Installation Of InK175 Keypad With Adhesive
in.stream TechBook Installation of in.k175 keypad with adhesive To install the ink175, select the most appropriate Gasket with adhesive location for the keypad and use the drilling template to cut the surface Clean the surface, peel the backing paper from the adhesive on the keypad and insert the ink175 into the hole (see illustration) Cut along 2.15 " 1.35 " Dashed line 2.78 " 3.58 "... -
Page 10: Wiring Diagram
in.stream TechBook Wiring diagram Speakers and supply connector blue black not used ground - yellow 12 V DC 12 V DC white grey front front left right white/black grey/black speaker speaker green violet rear rear left right speaker speaker green/black violet/black WARNING Green wire with Black Important note: White wire stripe... -
Page 11: Connecting The Keypad To InStream
in.stream TechBook Connecting the keypad to in.stream In.k175 configuration The instream system can be connected to an ink175 keypad This keypad allows control of volume, mute, play, pause and track changes The instream also has an auxiliary audio input, so it can provide the audio output for other, wired, accessories such as MP3 players or TVs The ink175 keypad comes with a 20' cable with an 8-pin mini-DIN male connector To connect the keypad, simply insert the male 8-pin mini-DIN connector into the receiving 8-pin mini-DIN labelled "wire remote connector" in the illustration Command Power & speakers in.k175 Audio stream Aux. input Wire remote connector in.k175 to 8 pin mini-DIN In.k113 configuration The instream system can also be used without an ink175 keypad A simple ink113 single switch can be used for the pairing function and to play/pause All the other ... -
Page 12: Wireless Set-Up
in.stream TechBook Wireless set-up Pairing with a Bluetooth technology enabled device Connecting to a Bluetooth technology enabled device The instream system is ready to pair when it is not Once the pairing is done and connection has been already connected to another device To pair your established between the devices, the instream will be device with the instream, first make sure you are close ready to start playing the selected audio enough to the instream system, and that it is turned on If the device moves out of range and loses connection it should reconnect automatically as soon as it is close enough This should happen without going through the 1 Open the Bluetooth settings on your device The location of the settings will depend on the device menu again you are using 2 In these settings, turn Bluetooth on, if it is not already 3 Choose "Gecko instream" from the list of available devices 4 When prompted, enter 5555 as the password Your device should now be paired with the instream system, and ready to use The instream will keep up to 8 devices in its memory If one of these devices is in range and has its Bluetooth turned on it will automatically pair with instream If the ... -
Page 13: Basic Operation/InK175
in.stream TechBook Basic operation/in.k175 (Unpair) Bluetooth (Disconnect) Volume Up Play/Pause (Power) Volume Down Next Track Last Track (Mute) (Fade) If you are using a device with Bluetooth technology, it Adjusting the volume must be connected for functions to work. Press the Volume Up or the Volume Down keys to increase or decrease the volume Please note that the Play/Pause and Change Track functions apply to devices using Bluetooth technology... -
Page 14: Basic Operation/InK113
in.stream TechBook Basic operation/in.k113 Single switch operation Erase all pairings It is possible to connect a single switch instead of a full Press and hold the the key for 10 seconds to erase all keypad The single switch can be used to play/pause, pairings from the instream memory and erase pairings Turning power On/Off Operation with the single switch: Please note that the unit will remain ON while being used in single switch mode There will be no way Play/Pause to turn it OFF The first single press on the key will send the wireless play/pause command to the remote device A second press on the key will send the command again, so the user can play and pause with successive presses... -
Page 15: Specifications
in.stream TechBook Specifications Part number 0704-100002 Environmental: Operating temperature: 140°F (60°C) to -4°F (–20°C) Storage temperature: 185°F (85°C) to -22°F (–30°C) Humidity: Up to 70% condensing Water ingress protection: IPX-5 Mechanical: Weight: 13 lb (06 kg) Dimensions (W x H x D): 8 ¼” x 6 ¾” x 2 ½” (210mm x 171mm x 64mm) Electrical specifications Input voltage: 138 V DC typical (10-145 V DC) Max input current: Up to 10 A Speaker impedance: 4Ω or 8Ω 1 ... - Page 16 9919-101176-D Gecko Alliance Rev. 08-2012 450 des Canetons, Quebec City (Qc), G2E 5W6 Canada, 1.800.78.GECKO 9225 Stellar Court, Corona, CA 92883 USA, 951.667 .2000 © Groupe Gecko Alliance Inc., 2012 All trademarks or registered trademarks www.geckoalliance.com are the property of their respective owners. Printed in China 08-2012 ClearStream manual | 1-13...
