INSTALLATION MANUAL
for frames:
Epson ELPMB50
Panasonic ET-RFD91 / ET-RFD91-li
Only a quali ed installer should install this product.
Read these instructions carefully before installing this product.
The frames and projectors shown in the pictures of this manual only serve as an example.
The design of the frame and projector you are using may vary.
These installation instructions must always be handed over to the installing person.
2
3
3
4
4
5
Advertisement
Table of Contents
Summary of Contents for Lang TH-SHORTY-60-6
-
Page 1: Table Of Contents
INSTALLATION MANUAL TH-SHORTY-60-6 Important safety notice Product description Maximum weight load information Installing the truss mount Adjustment options Dimensions for frames: Epson ELPMB50 Panasonic ET-RFD91 / ET-RFD91-li Only a quali ed installer should install this product. Read these instructions carefully before installing this product. -
Page 2: Th-Shorty-60-6
Installation work should only be carried out by a quali ed technician. - If this product is not installed correctly, serious accidents may result. The maximum weight load for one TH-SHORTY-60-6 is 60 kg (132,28 lb.) - Do not exceed the maximum weight load in ceiling mount con gurations. -
Page 3: Product Description
PRODUCT DESCRIPTION Parts name Image Purpose Finished assembly diagram Truss mount Used for ceiling mount installations MAXIMUM WEIGHT LOAD INFORMATION Epson ELPMB50 Panasonic ET-RFD91 / ET-RFD91-li TH-SHORTY-60-6... -
Page 4: Installing The Truss Mount
INSTALLING THE TRUSS MOUNT Place the truss mount on the rear side of the frame. Make sure that the 4 screws enter the 4 holes in the frame. Tighten the screws to secure the truss mount on the frame. ADJUSTMENT OPTIONS 360°... -
Page 5: Dimensions
DIMENSIONS... - Page 8 Made in Germany by Sager Metallbearbeitung www.lang-ag.com 12/16...
