- Page 1 Adam Equipment AE RELAY ACCESSORY P.N. 3106611295, Revision B, Mar 2016 © 2016 Adam Equipment...
- Page 2 © 2016 Adam Equipment...
- Page 3 DANGEROUS VOLTAGES may be present. Only qualified personal should attempt the connection of the relay to user equipment DANGEROUS VOLTAGES can cause physical injury and/or damage to the equipment © 2016 Adam Equipment 3106611295RevB-Mar16...
- Page 4 INSTALLATION The AE 402 indicator is supplied with drivers to control external relays. The drivers could be used to control a number of different relays depending upon the users need. The relay drivers are isolated outputs requiring the use of an external power supply for the relays.
- Page 5 OUT1 to OUT4. The relay active for each LED will depend on the input connection, Input IN1 controls relay 1, OUT1 for example. But IN1 could be connected to any of the 4 terminals in the AE 402. CAUTION: The voltage and current limits of the relay outputs must be less than: 115/230VAC, 1amp or 24VDC.
- Page 6 WARRANTY STATEMENT Adam Equipment offers Limited Warranty (Parts and Labour) for any components that fail due to defects in materials or workmanship. Warranty starts from the date of delivery. During the warranty period, should any repairs be necessary, the purchaser must inform its supplier or Adam Equipment Company.
- Page 7 2014/35/EU EN61010-1:2010 – Part 1: 2011/65/EC, RoHS 2 EN50581: 2012, Signed for and on behalf of: Adam Equipment Company Ltd. United Kingdom, 20 Feb 2016 Clive Jones, Quality & Product Manager. WEEE 2012/19/EU This device may not be disposed of in domestic waste. This also applies to countries outside the EU, per their specific requirements.
- Page 8 © Copyright by Adam Equipment Co. All rights reserved. No part of this publication may be reprinted or translated in any form or by any means without the prior permission of Adam Equipment. Adam Equipment reserves the right to make changes to the technology, features, specifications and design of the equipment without notice.
