- Page 1 Dosing system Speed Control plug’n’dose Operating and maintenance instructions Translation of the German original operating manual...
- Page 2 Printed 22.1.16...
-
Page 3: Table Of Contents
plug’n’dose AM Operating and maintenance instructions Contents Introduction Function description Scope of supply Safety Informal safety measures - - - - - - - - - - - - - - - - - - - - - - - 5 Use of symbols - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5 Correct use, warranty - - - - - - - - - - - - - - - - - - - - - - - - - 5 Qualifications of the operators and maintenance personnel - - - - - - 5... -
Page 4: Introduction
plug’n’dose AM Operating and maintenance instructions Introduction Dear customer, Congratulations on the purchase of your control system. We are confident that it will meet all of your requirements. We trust that the unit will give you trouble-free and successful service. The plug’n’dose AM dosing system consists of a dosing control and a dispenser. -
Page 5: Safety
plug’n’dose AM Operating and maintenance instructions Safety Informal safety measures » The operating and maintenance instructions should always be kept at the location where the control system is in use. » General and local regulations on health, safety and environmental protection must also be provided and complied with. -
Page 6: Organisational Measures
plug’n’dose AM Operating and maintenance instructions Organisational measures The necessary personal protective equipment must be provided by the operating organisation. All safety devices that are fitted must be checked regularly. Safety glasses and overalls must be worn during operation and cleaning to provide protection against any splashes of chemicals. -
Page 7: Operation
plug’n’dose AM Operating and maintenance instructions Operation Before the control system is operated, the safety information in Chapter 4, Safety, beginning on page 5, must have been read and understood. Displays and controls / connections Item Function, description Displays the operating modes •... -
Page 8: Important For Signal Definition
plug’n’dose AM Operating and maintenance instructions Important for signal definition The amount of medium that is drawn back in by the suck-back must only be just enough to prevent dripping. If more is sucked in, air will enter the dispenser and the medium will emerge late at the next dosing. -
Page 9: Shutting Down
plug’n’dose AM Operating and maintenance instructions Shutting down The unit is shut down in reverse order of setting up. Operation The control system is operated according to the control signals from the master controller that are present at the connector (1) (see 5.4). The dosing quantity depends on the connected dispenser. -
Page 10: Disposal
This unit complies with RoHS requirements. EC-Declaration of Conformity in accordance with the EC-Machinery Directive 2006/42/EG, Appendix II A ViscoTec Pumpen- und Dosiertechnik GmbH Amperstraße 13 D-84513 Töging hereby declare that the machinery described below complies in its design and construction and in the version marketed by us with the basic safety and health requirements of the EC Directive 2006/42/EG. - Page 11 plug’n’dose AM Operating and maintenance instructions This is the last page in this document Notizen Copyright © Version 1.3 11 / 11...
