Reese 56007 Installation Instructions Manual

1999-2013 1500/2500LD GMC/Chevy (All Models) See Page 3 Or 5
WARNING:
Under no circumstances do we recommend exceeding the towing vehicle manufacturers recommended vehicle towing capacity.
READ ALL INSTRUCTIONS BEFORE STARTING THE INSTALLATION
REESE ® Custom Quick Install mounting brackets only include the hardware to attach the custom brackets to the frame.
10 BOLT INSTALLATION
Vehicle Forward
7 8
Depending on Truck Model,
11
Reinforcement Block Location
Could Change
# Description
1 Driver Side Mounting Bracket
2 Passenger Side Mouting Bracket
3 5/8"-11 Hex Nut
4 5/8" Concial Washer
5 Angle Bracket
6 5/8"-11 Gr. 8 Button Head Cap Screw
© 2014, 2015 Cequent Performance Products
Installation Instructions
REESE ® CUSTOM QUICK INSTALL MOUNTING KIT
FOR 30153 REESE
2001-2010 2500/3500 GMC/Chevy (All Models) See Page 1
10 9
3 4
QTY
1
1
2
2
1
2
- Printed in Mexico
® RAILS ONLY
Equipment Required:
Fastener Kit: 56007F
Wrenches: 3/4", 15/16"
Drill Bits: 1/8", 9/16"
Other Tools: Center Punch, Measuring Tape, 3/8" Allen
Head Socket
2
1
5
6
Angle Bracket
# Description
7 1/2"-13 Hex Nut
8 1/2" Concial Washer
9 1/2"-13 X 5.5" Gr. 8 Carriage Bolt
10 Reinforcement Block
11 5/8" Pull Wire
12 5/8" Flat Washer
Sheet 1 of 7
Plug
Inside driver side frame rail
Loosen two
flange bolts
Outside driver side frame rail
Figure 1
(Included)
QTY
4
4
4
4
2
2
56007N 3-27-15
Part Number:
56007
Inner Driver
side frame rail
Figure 2a
Figure 2b
Figure 2c
Any hardware shown in
Figure 1, but not
described in table below
were supplied with
30153 kit.
Rev. D
