- Page 1 TSL.R.030 ribbon hand dryer...
- Page 2 contents Safety and Warnings Box Contents Technical Data Before You Install How to Install Commissioning Operation Maintenance Cleaning Troubleshooting Diagram Spare Parts / Accessories Warranty Back Cover Contact Details TSL.R.030 RIBBON HAND DRYER MANUAL...
- Page 3 TSL.R.030 ribbon hand dryer Read and save these instructions WARNING To reduce the risk of fire, electric shock or injury to persons, observe the following: Use this unit only in the manner intended by the manufacturer. If you have any questions, contact the manufacturer (see back page for details) This equipment should be installed in a way that ensures all electrical parts are kept dry.
-
Page 4: Box Contents
box contents Dryer head assembly Hand dryer motor unit Power cable Anti-rotation collar (already installed) Gasket Anti-rotation washer Fixing nut Motor mounting screws Hex wrench Air hose TSL.R.030 RIBBON HAND DRYER MANUAL... -
Page 5: Technical Data
technical data Finishes TSL.R.030.C.E120 Bright Polished Stainless steel TSL.R.030.CS.E120 Brushed Stainless steel TSL.R.030.CP.E120 Brushed Copper TSL.R.030.BK.E120 Brushed Black TSL.R.030.BR.E120 Brushed Brass TSL.R.030.BZ.E120 Brushed Bronze Voltage 110 - 120V ac; 60Hz Current 7.6 - 8.4A Power consumption 0.84 - 1.0kW Standby power 0.3 - 0.4kW Drying time <15 seconds... -
Page 6: Before You Install
The standard US 120V 15 Amp circuit should only use up to 12 of its 15 Basins amps. Use of a The Splash Lab Monolith basin Spacing is recommended for use with the Ribbon range of products. If the Ribbon hand dryer is installed with... - Page 7 before you install FRONT SIDE Default S ensor 7-5/16" R ange 2-1/8" 3/4"-5-1/8" 6" Ø 1-5/16" THR OUGH HOLE Ø 1-1/4" 2-11/16" Mains Power S upply 10-3/4" 12-1/16" 5-7/8" TSL.R.030 RIBBON HAND DRYER MANUAL...
-
Page 8: How To Install
how to install Drill hole 1 3/8” diameter in counter-top, if Fit anti-rotation washer from below basin not already cut. TSL.R.030 RIBBON HAND DRYER MANUAL... - Page 9 Fit fixing nut, and secure using spanner. Remove cover-fixing screws from underside of dryer motor using the security hex key provided, and then remove the cover. TSL.R.030 RIBBON HAND DRYER MANUAL...
- Page 10 how to install Fit the dryer motor unit to wall or cabinet, Thread the power cable through the within 18” of the dryer nozzle already knockout in the back or base of the dryer installed on the basin / countertop. and feed to connector block.
- Page 11 Thread the sensor and earth cables Feed cables into air outlet nozzle and through the air-hose. then through cable exit grommet. TSL.R.030 RIBBON HAND DRYER MANUAL...
- Page 12 how to install Connect the sensor cable to the 6-pin Connect air hose onto outlet nozzle on fitting on the PCB control, and the dryer motor and tighten hose clamp. ground cable to the corresponding earth connector in the dryer motor unit. TSL.R.030 RIBBON HAND DRYER MANUAL...
- Page 13 Re-fit the dryer cover and tighten the fixing screws. TSL.R.030 RIBBON HAND DRYER MANUAL...
- Page 14 commissioning Turn on the power supply to the dryer, and then test that the dryer will operate when the user’s hands are placed within the detection range. The motor speed and sensor range can be adjusted to suit user preference and the environment, if required.
- Page 15 Heater Element Switch ON/OFF Switch off the power, loosen the cover screws and remove the cover. Adjust the heater switch on the PCB with a small plastic or wood flat blade probe. Slide the switch to ‘ON’ : Enables heater 2-2 Slide the switch to ‘1’...
-
Page 16: Operation
operation The user is to shake excess water off their hands. The user then places their hands within the detection range of the sensor to activate the hand dryer. The motor will start and air is blown onto the user’s hands. The motor will stop when the user’s hands are removed from the detection range. - Page 17 If further information is required, contact The Splash Lab technical team for more detailed stainless-steel care guidelines. TSL.R.030 RIBBON HAND DRYER MANUAL...
-
Page 18: Troubleshooting
troubleshooting Corrective Actions for Initial Installation Failures If the dryer will not run: First ensure that the breaker supplying the dryer is operational. If it is, disconnect the power and remove the dryer cover. Taking suitable precautions to avoid shock hazard, reconnect the power and check for voltage at the terminal block. - Page 19 Corrective Actions for Initial Installation Failures If the dryer will not run: First ensure that the breaker supplying the dryer is operational. If it is, disconnect the power and remove the dryer cover. Replace the CBM and IR sensor module. Taking suitable precautions to avoid shock hazard, reconnect the power and check for Voltage at the terminal block.
- Page 20 troubleshooting Corrective Actions for Initial Installation Failures The dryer only blows cold air during a full cycle: Disconnect the power. Remove the dryer cover and check/ ensure heater switch is ON. Disassemble the blower-motor/fan housing. Test the thermostat for open circuit.
- Page 21 diagram TSL.R.030 RIBBON HAND DRYER MANUAL...
-
Page 22: Spare Parts And Accessories
Mounting nut Motor mounting rubber – Upper Blower motor housing – If further information is required, upper section contact The Splash Lab technical team Stainless steel front cover plate for more detailed guidelines. Motor cover fixing screws (2 required) Hex wrench... -
Page 23: Warranty
Ribbon Collection 3 years’ parts & labour If a defect is found in normal use, The Splash Lab will, at their discretion, repair, provide a replacement part or product, or make appropriate adjustments. Damage caused by accident, misuse, or abuse is not covered by this warranty. Improper care and cleaning will void the warranty. - Page 24 contact General information +1 310 410 5008 5450 W 83rd St, Los Angeles CA90045 500 7th Ave, New York NY10018 Technical support technical@thesplashlab.com For further contact information visit: www.thesplashlab.com...
