- Page 1 Universal bracket Instructions for Use for one-pipe concealed ventilators, manifolds, water meters, heat flow meters Model Year built: 8062.5 from 02/1997 en_INT...
- Page 2 Universal bracket 2 from 11...
-
Page 3: Table Of Contents
Table of contents Table of contents About these instructions for use Target groups Labelling of notes About this translated version Product information Standards and regulations Intended use 2.2.1 Areas of use Product description 2.3.1 Overview 2.3.2 Sound protection Handling Assembly information 3.1.1 Mounting conditions 3.1.2... -
Page 4: About These Instructions For Use
This restriction does not extend to possible operating instructions. The installation of Viega products must take place in accordance with the general rules of engineering and the Viega instructions for use. -
Page 5: About This Translated Version
About these instructions for use About this translated version This instruction for use contains important information about the choice of product or system, assembly and commissioning as well as intended use and, if required, maintenance measures. The information about the products, their properties and application technology are based on the current standards in Europe (e. -
Page 6: Product Information
Standards and regulations The following standards and regulations apply to Germany / Europe. National regulations can be found on the relevant web site of your viega.com/standards . country at Regulations from section: Fields of application / Mounting conditions Scope / Notice... -
Page 7: Product Description
Product information Product description 2.3.1 Overview Fig. 1: Scope of delivery 1 - slot nuts 2 - universal bracket 3 - fixing material 2.3.2 Sound protection The model complies with the noise insulation requirements specified in Ä „Regulations from section: Sound protection“ on page 6 . section Universal bracket 7 from 11... -
Page 8: Handling
Handling 3 Handling Assembly information 3.1.1 Mounting conditions Construction height With the construction height, the marked height of the upper edge of the finished floor must be observed. 3.1.2 Installation dimensions Fig. 2: Dimensions 3.1.3 Required tools The following tools are required for mounting: fork or ring spanner: 17 mm / 19 mm Universal bracket 8 from 11... -
Page 9: Assembly
Handling Assembly 3.2.1 Mounting module Mounting in Steptec The two vertical rails, which surround the module, must be open towards the module and be at an interval of 430 mm. Secure the element onto the open Steptec rail with the slot nuts supplied: Insert the slot nut into the opening of the module. -
Page 10: Rounding Off Jobs
Handling Tighten the other slot nuts in the same way. ð The module is secured on the rail framework. Check height and width settings. Check settings. When doing so, also observe the equipment manufacturer's instruc- tions. Make sure that the fixing ends flush with the rail framework. The fixing may extend for a maximum of 1.5 mm beyond the rail frame- work. -
Page 11: Disposal
Handling Single clad pre-wall: Clad with 12.5 mm wide IFGP or 12 mm wide Aqua-KS cladding panels. When doing so, make sure that no abutting edges converge. Grout the abutting edges and joints with a suitable filler. Observe the instruction manual for the cladding panels for more information.
