Thank you for purchasing a Bridge Key USB
Communications Kit.
The Bridge Key is compatible with a range of
Define Instruments products, and contains
the hardware required for PC connection to
your compatible device:
1x Bridge Key
Universal USB programming key
1x Head mount adapter*
Required for head mount transmitters
only (TM-2HL & TM-2HLI)
* Not included with special offer Bridge Keys.
SAFETY NOTICES
Please read and carefully observe all safety regulations and instructions contained in this
manual, and the user manual for your Bridge Key compatible product.
CAUTION - Risk of danger
Use of this product in a manner not specified by the manufacturer may cause damage to
the Bridge Key, your PC, or other connected equipment. Please refer to the documentation
wherever this symbol is marked on your Bridge Key (or Bridge Key compatible product).
QUICK START
Consult user
manual (p2)
Copyright © 2016 Define Instruments
Install
software (p3)
Bridge Key
USB Communications Kit
1x Interface cable
Connects the Bridge Key to your device
1x USB extension cable*
Used if the computer's USB port is
difficult to access
Connect
cables (p3)
BRIDGE-KEY-MAN-16V04 (1124)
1
Plug in
Bridge Key
(p4)
