LIGMAN ZE-50019 Installation And Service Manual

INSTALLATION AND SERVICE MANUAL
For Installation of Zeat small floodlight COB.
Model. ZE-50019 and ZE-50020
Product drawing (dimensions)
102
182
110
(Brown)Vdc+
(Blue)Vdc-
Torque :1.0Nm.
■ LIGMAN standard products are supplied with the control gear 220-240V 50/60Hz.
The control gear for other voltages and frequencies is available upon request, please consult us for more details.
■ LIGMAN luminaires are designed to conform IEC 60598 2-5 standard.
Technical amendments and modifications techniques reserved.
L i g m a n L i g h t i n g
Europe Headquarters
Ligman Europe s.r.o.
VGP Park Usti nad Labem, P 2
Prestanov 113
403 17 Prestanov
Czech Republic
Tel. +420 608 740 504 sales.cz@ligman.com
|
www.ligman.com
142
37
1
4
Thailand Headquarters
Ligman Lighting Co., Ltd.
17/2 Moo 4, Monthong, Bangnampreaw
Chachoengsao 24150 Thailand
Tel : +66 (2) 7339140
info@ligman.com
M ZE-50019/17/03/18/REV.2
90°
96
47
45°
MOUNTING DETAIL
2
L
N
5
Torque :0.25Nm.
1/2
IP65 IK04 CLASS lll
Ø5.5
Weight : 1Kg.
30
6
CABLE SIZE : 2x1.0mm
~1cm.
Torque :3.0Nm.
Torque :4.3Nm.
Ligman Ltd
Regus House, Victory Way
Crossways Business Park
Dartford DA2 6QD
Tel. 0800 975 0622
sales.uk@ligman.com
FM-TS-13-1/13-03-2561/REV.4
0.3m
3,4
TOOL
3
10
².
OD.6-10mm.
6
