3B BMC Luna CPAP Patient Set-Up Manual

Luna CPAP & Auto-CPAP Patient Set-Up Manual
1.

Button Functions

Mute Button: Silences the alarm and displays iCode
Dial: Starts CPAP pressure and adjusts device settings
Ramp Button: Press it to enable the Ramp feature
2.

Setting up the Device

Power Outlet
A. Connect one end of the tube to the assembled mask.
B. Connect the other end of the tube securely to the air outlet of the main device or of the
humidifier, as shown in the figure above.
C. Connect the power adapter to the DC inlet of the main device.
D. Connect the power cord to the power adapter.
E. Plug the power cord into the power outlet.
3.

Adjusting Device Settings

A. After the device is connected to power, its screen displays the Main Interface shown in the left
figure below (only applies to Luna Auto-CPAP), or the Main Interface shown in the right figure
below (only applies to Luna CPAP).
B. From the Main Interface shown above, press and hold the Ramp Button
seconds. The screen displays the Initial Setup Interface, as shown in the figure below.
Luna CPAP & Auto-CPAP Patient Set-Up Manual V1.3
A
Mask
Power Cord
Power Adapter
D
1 / 2
®
strings
Air Outlet of the
Humidifier
B
Tube
C
C
C
C
DC Inlet
Air Outlet
Main Device
for three
