Bayside Furnishings Ario 3-in-1 ARI3N1CGT Manual

Tv stand
Hide thumbs
Table of Contents

Advertisement

Quick Links

Ario 3-in-1
Model # ARI3N1CGT
U.S. Patent 8,561,551 and other Patent Pending
This item is designed to be a 3-in-1 configuration. Please choose the option that best suits your
needs. DO NOT discard any of the hardware or parts that you will not use on your chosen option.
This will allow you to use this TV Console in different configurations at a later date, if desired.
ADULT ASSEMBLY REQUIRED
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
www.baysidefurnishings.com
ONLINE:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Bayside Furnishings
TM
TV Stand
On-line Video Instruction Guides
Go to http://vig.sellpoints.com to view step-by-step instructional
videos for assembling and installing your product. Enter the
following product number on the website under Whalen brand.
ARI3N1CGT
®
Date 2014-09-13 Rev. 3 Factory: FOCIDI
TV
877-494-2536
parts@baysidefurnishings.com
EMAIL:
Page 1
LOT NUMBER:
DATE PURCHASED:
TV
Factory No. 10944
/
/

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ario 3-in-1 ARI3N1CGT and is the answer not in the manual?

Questions and answers

Related Manuals for Bayside Furnishings Ario 3-in-1 ARI3N1CGT

Summary of Contents for Bayside Furnishings Ario 3-in-1 ARI3N1CGT

  • Page 1 Enter the following product number on the website under Whalen brand. ARI3N1CGT THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. ® Bayside Furnishings Page 1 Factory No. 10944 Date 2014-09-13 Rev. 3 Factory: FOCIDI...
  • Page 2 Model # ARI3N1CGT M A X I M U M R E C O M M E N D E D W E I G H T L O A D S ® MANUFACTURER: Bayside Furnishings CATALOG: Ario 3-in-1 TV Stand (ARI3N1CGT)
  • Page 3 M- SSS Spine (1) N- Sensor/Sound shelf (1) O- Cable Wheel (2) (1) Suction Cup (2) 1/2” Bolt w/Teflon (3) 3/4” Bolt (4) 1-1/2” Bolt (12+1 extra) (8+1 extra) (12+1 extra) (18+1 extra) ® Bayside Furnishings Page 3 Factory No. 10944...

  • Page 4: Table Of Contents

    M6 Lock Washer (4) M8 Lock Washer (4) Large Spacer (4) Small Spacer (4) M4/M5 Flat Washer (8) M6/M8 Flat Washer (4) Tools required: Allen wrench (provided) and Phillips screwdriver (not provided). ® Bayside Furnishings Page 4 Factory No. 10944...

  • Page 5: Factory

    Spine (D). Make sure that the inside corner plates on the shelf frames will face up when the unit is turned upright. NOTE: The Middle Shelf Frame (B) is adjustable. Choose the upper hole sets to increase the bottom space. ® Bayside Furnishings Page 5 Factory No. 10944...
  • Page 6 Bottom Metal Frame (C). Insert four 1-1/2” Bolts (4) with the Washers (5 and 6) through the pre-drilled holes on the Bottom Metal Frame (C) and screw into the threaded inserts underneath the Drawer Box (G). DO NOT tighten the bolts in this step. ® Bayside Furnishings Page 6 Factory No. 10944...
  • Page 7 Secure the Left Leg (E) to the Bottom Metal Frame (C) by using one 3/4” Bolt (3) with the Washers (5 and 6) through the end bracket and screw into place. As shown. 9. Repeat last two steps with the Right Leg (F). ® Bayside Furnishings Page 7 Factory No. 10944...
  • Page 8 NOTE: If the drawer does not go in smoothly, please take it out and repeat the step. ® Bayside Furnishings Page 8 Factory No. 10944...

  • Page 9: Cord

    Frame (A) using the provided 1/2” Screws (10). Tighten the screws with a Phillips screwdriver. If you choose Table-top Console configuration, continue to the next step. If mounting TV with the Floating Swivel Mount, skip ahead to PAGE 14. ® Bayside Furnishings Page 9 Factory No. 10944...
  • Page 10 Upper Spine. So that you can use the table top console configuration. NOTE: Keep the Upper Spine and the fasteners at a proper place in case you will use the floating swivel mount. ® Bayside Furnishings Page 10 Factory No. 10944...

  • Page 11: Spine End

    16. Attach 2 Cable Wheels (O) to the backside of the Lower Spine (D) with the 3/4” Bolts (3). Tighten the bolts with the provided M4 Allen Wrench. NOTE: You can use the Cable Wheels to help keep your entertainment center’s cables and cords organized. ® Bayside Furnishings Page 11 Factory No. 10944...
  • Page 12 Cups to make sure they securely rest onto the Suction Cups. NOTE: If a glass shelf is scratched, you can minimize the damage by using a BLACK marker and filling in scratched area from underneath. ® Bayside Furnishings Page 12 Factory No. 10944...
  • Page 13 20. The console is now ready for use. Be sure to position your Flat Panel TV in the center of the console. proceed to PAGE NOTE: If you choose the Tilting Wall Mount configuration, ® Bayside Furnishings Page 13 Factory No. 10944...
  • Page 14 M4 Allen Wrench. NOTE: The Spine can provide four height options for the TV set. Refer to your TV size and adjust the Swiveling Bracket to the desired height for optimum viewing. ® Bayside Furnishings Page 14 Factory No. 10944...
  • Page 15 Adjust the height of SSS Spine so that it will be the correct distance above or below your TV and attach it in place using the 1/2” Bolts (2) with the Washers (5 and 6). ® Bayside Furnishings Page 15 Factory No. 10944...
  • Page 16 23. Hold and attach the flat side of the Mounting Frame (K) onto the Swiveling Bracket (J) using four 1/2” Bolts (2) and four Washers (5 and 6). Make sure that the recess holes on the Mounting Frame are at the bottom. ® Bayside Furnishings Page 16 Factory No. 10944...
  • Page 17 24. Pick up the Sensor/Sound Shelf (N) and securely fit the back tabs into the small slots of the SSS Spine (M). Tighten both Lock Bolts which are pre-attached on the SSS Spine with a Phillips screwdriver until they hit the back tabs of Sensor/Sound Shelf. ® Bayside Furnishings Page 17 Factory No. 10944...
  • Page 18 NOTE: Lean the TV up against a wall or other solid surface when attaching with the Monitor Brackets. DO NOT place the TV face down on the glass as this may cause permanent damage to the TV. ® Bayside Furnishings Page 18 Factory No. 10944...
  • Page 19 NOTE: Lean the TV up against a wall or other solid surface when attaching with the Monitor Brackets. DO NOT place the TV face down on the glass as this may cause permanent damage to the TV. ® Bayside Furnishings Page 19 Factory No. 10944...
  • Page 20 30. Center the television and tighten both Lock Bolts with a long Phillips screwdriver until they hit the underside of the Mounting Frame (K) to ensure your TV is safe and secure. ® Bayside Furnishings Page 20 Factory No. 10944...
  • Page 21 31. The Monitor Brackets (LL/LR) can tilt up to 11˚ downward and 5˚ upward, depending on your optimum viewing position. Keep the enclosed 3/16” Allen Wrench to ensure the Tilt Adjustment Knobs remain tightly fastened. ® Bayside Furnishings Page 21 Factory No. 10944...
  • Page 22 NOTE: YOU MUST USE THIS TIPPING RESTRAINT TO ATTACH THIS UNIT TO THE WALL, TO PREVENT THE UNIT FROM TIPPING, CAUSING ACCIDENTS AND/OR INJURIES. 34. The console is now ready for use. Swivel the TV left-or-right for optimum viewing control. ® Bayside Furnishings Page 22 Factory No. 10944...

  • Page 23: Concrete

    37. Secure the Mounting Frame (K) to wall with the Lag Bolts (8) and the Washers (9) at the drill points. Tighten the bolts firmly, but be careful not to over tighten. ® Bayside Furnishings Page 23 Factory No. 10944...
  • Page 24 40. Place the Mounting Frame (K) level in the desired position against the wall. Secure the Mounting Frame (K) to wall with the Lag Bolts (8) and the Washers (9) at the drill points. Tighten the bolts firmly, but be careful not to over tighten. ® Bayside Furnishings Page 24 Factory No. 10944...
  • Page 25 45. Repeat the step 24 to install the Sensor/Sound Shelf (N) onto the SSS Spine (M). 46. Place the assembled console under your TV. Finally, connect the A/V and power cables to your TV. You are now ready to enjoy your wall-mounted Flat Panel TV. ® Bayside Furnishings Page 25 Factory No. 10944...

  • Page 26: Care And Maintenance

    Should this product be defective in workmanship or materials or fail under normal use, we will repair ® or replace it for up to one (1) year from date of purchase. Every Bayside Furnishings product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
