Au
IMPORTANT SAFETY INSTRUCTIONS
WARNING - BURST HAZARD
Do not use the unit for charging dry-cell batteries that are commonly used with home appliances. These batteries may burst and
cause injury to persons and damage property. Use the unit for charging/boosting a LEAD-ACID battery only.
WARNING - SHOCK HAZARD
• Do not operate unit with damaged cord or plug; or if the unit has received a sharp blow, been dropped, or otherwise
damaged in any way. Do not disassemble the unit; incorrect reassembly may result in a risk of electric shock or fire.
• NEVER submerge this unit in water; do not expose it to rain, snow or use when wet.
• To reduce risk of electric shock, disconnect the unit from any power source before attempting maintenance or cleaning.
WARNING - RISK OF EXPLOSIVE GASES:
• Working in the vicinity of a lead acid battery is dangerous. Batteries generate explosive gases during normal battery
operation.
• If battery acid contacts skin or clothing, wash immediately with soap and water for at least 10 minutes and get medical
attention immediately.
• Do not operate this unit in a closed area or restrict ventilation in any way.
PRODUCT FEATURES
•
For all 6V and 12V lead acid batteries (WET, MF, AGM and GEL);
•
Charging voltage auto select;
•
Charging current selection;
•
No risk of over charging; Charger will go into maintenance mode for long term charging.
•
Electronically safe against user error with LED indicator;
•
Spark proof;
•
Over heat protection;
•
Full protected against short circuit and wrong connections;
•
With LED indicators;
•
12V battery recovery:
•
For 12V batteries voltage lower than 8V, you can use the charger to recover the battery.
Recovery Operation Steps:
1. Plug in the AC power without the connection with the battery;
2. Press the MODE button for 3~5 seconds until the 12V LED indicator comes on;
3. Now connect the output clamps/terminal rings with the battery correctly or use cigarette
lighter adapter. Cigarette lighter of accessory socket must be live with car off to work.
4. The charger begins charging with 1.5A low current to recover the battery, which terminates when the voltage reaches to
10.5V ± 0.25V, and then it switches over to regular charging mode.
OPERATING INSTRUCTIONS
1. Connecting the terminal rings/clamps directly to the corresponding connectors on the battery posts.
Note: Make sure correct polarity connection before plugging in the AC power.
• Position the RED terminal on the POSITIVE post connector
• Position the BLACK terminal on the NEGATIVE post connector
Automatic Battery Charger
For 6V and 12V Lead-acid batteries
R
1
Advertisement
Table of Contents
Summary of Contents for Schwaben Automatic Battery Charger
-
Page 1: Important Safety Instructions
Automatic Battery Charger For 6V and 12V Lead-acid batteries IMPORTANT SAFETY INSTRUCTIONS WARNING - BURST HAZARD Do not use the unit for charging dry-cell batteries that are commonly used with home appliances. These batteries may burst and cause injury to persons and damage property. Use the unit for charging/boosting a LEAD-ACID battery only. - Page 2 2. Connect the AC power cord with the AC power outlet. • The Power LED indicator turns on after the connection. • The charger will automatically select the right voltage according to the battery voltage type and the corresponding LED indicator will turn on. 6V Batteries 12V Batteries •...
