Pan/Tilt/Zoom Receiver Programming
A Kalatel pan/tilt/zoom receiver has several mode-of-operation choices that you must program for the
receiver to function as desired. Typically, the receiver is programmed with a Kalatel controller keypad, but
it can also be programmed manually, as described in these installation instructions.
P
R
ROGRAMMING THE
1)
Disconnect power from the receiver.
2)
Place the receiver in programming mode (see Figures 1 and 2).
Figure 1. Placing the KTD-125B in programming mode
3)
Set DIP switches for the desired mode of operation (see Table 1).
Table 1. Setting DIP switches for the desired mode of operation
DIP Switch 1
Zoom Polarity
DIP Switch 2
Iris Polarity
DIP Switch 3
Pan/Tilt Drive
DIP Switches 4 and 5
Autopan*
DIP Switch 6
Autopan on Power-Up
DIP Switch 7
Zoom Lens Voltage
DIP Switch 8
Invert Up and Down Tilt
*The KTD-128 does not have an autopan function.
For Technical Support and Sales call 800-469-1676
ECEIVER
1=OFF
Zoom in positive, zoom out negative
2=OFF
Iris open positive, iris close negative
3=OFF
Not DC motors
4=OFF 5=OFF
Normal
4=OFF 5=ON
Random pan
6=OFF
Yes
7=OFF
12 VDC
8=OFF
Not inverted
KTD-128 receiver card
Figure 2. Placing the KTD-128 and KTD-125C in programming
mode
Zoom in negative, zoom out positive
Iris open negative, iris close positive
50% duty cycle
Disable autopan
KTD-125C receiver card
1=ON
2=ON
3=ON
DC motors
4=ON 5=OFF
4=ON 5=ON
6=ON
No
7=ON
6 VDC
8=ON
Inverted
1035406B / January 2002
1
Advertisement
Table of Contents
Summary of Contents for KALATEL KTD-125C
- Page 1 A Kalatel pan/tilt/zoom receiver has several mode-of-operation choices that you must program for the receiver to function as desired. Typically, the receiver is programmed with a Kalatel controller keypad, but it can also be programmed manually, as described in these installation instructions.
- Page 2 KTD-125C receiver card Figure 3. Placing the KTD-125B in normal mode Figure 4. Placing the KTD-128 and KTD-125C in normal mode To change mode-of-operation choices, repeat steps 1 through 5. Note: When reentering programming mode, all mode-of-operation choices must be reprogrammed, even if only one is being changed.
- Page 3 Pan/Tilt/Zoom Receiver Programming A. A DIP Switch Values PPENDIX SSIGNING One way to determine which switches to use is to subtract the highest possible switch value from the address you want, then subtract the highest possible switch value from that difference. Continue to subtract the highest possible switch value from the difference until you have zero.
