Extended Neck Mini Angle Grinder
Safety Instructions
WARNING Read all safety warnings
and all instructions.
Failure to follow the warnings and instructions may
result in electric shock, fire, and/or serious injury.
Save all warnings and instructions for future reference
About The Symbols
Various symbols are used in this manual and on the product
itself to ensure correct usage, to prevent danger to the user
and others, and to prevent property damage. The meanings
of these symbols are described above. It is important that
you read these descriptions thoroughly and fully understand
the contents.
DWA Series B
Model #
To reduce the risk of injury, user
must read instruction manual
Always Wear Eye Protection
Always Wear Gloves
Always Wear Hearing Protection
Class II Tool—Double Insulated
1
F
Advertisement
Table of Contents
Summary of Contents for DWA B Series
-
Page 1: Safety Instructions
DWA Series B Extended Neck Mini Angle Grinder Model # Safety Instructions WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire, and/or serious injury. Save all warnings and instructions for future reference... - Page 2 TABLE OF CONTENTS Cover Page Putting Tool in Use Table of Contents Tool Diagram Work Area Safety Changing Accessories Electric Safety Adjusting Safety Guard Personal Safety Holding the Tool General Safety Instructions 7 Maintenance & Service 3 Tool Use and Care Grinding / Cutting–...
-
Page 3: Personal Safety
PERSONAL SAFETY Stay alert, watch what you’re doing, and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol, or medication. A moment of inattention while operating the tool may result in serious personal injury. - Page 4 POWER TOOL USE AND CARE Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. Do not use the power tool if the paddle switch does not turn it on and off.
-
Page 5: Operating Instructions
Hold the paddle lever down during use to keep the motor running continually. The tool should turn off when the paddle switch is released. DWA Series B Model 1F Extended Neck Mini Angle Grinder Fixed Speed 120 Volt Motor: 0.7 A 120V... - Page 6 Adjusting The Safety Guard Disconnect the plug from its power source before adjusting the safety guard. Release the set screw (#1) using the hex key (#2). Turn the safety guard (#3) to the desired position, making sure it will protect your fingers during operation. Retighten the set screw (#1) and check that the safety guard (#3) is properly and securely seated on the...
- Page 7 GENERAL SAFETY INSTRUCTIONS This power tool is intended to function as a grinder, sander, carving or cut-off tool. Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury.
- Page 8 GRINDING AND CUTTING-OFF OPERATIONS Use only wheel types that are recommended for your power tool and only for recommended applications. For example: do not grind with the side of a cut-off wheel. Abrasive cut-off wheels are intended for peripheral grinding, side forces applied to these wheels may cause them to shatter.
