2019/11/2
MokoLife User Manual
WiFi wall switch WS001-3
Version
1.0
1.1
Wiring Method
SW1 LED Indication
NO
1
2
3
4
http://doc.mokotechnology.com/index.php?s=/page/5
Revision record
Initial version
Add LED indicator
LED State
Solid red
Solid blue and red
at the same time
Blink blue once
Blink red rapidly
ShowDoc
Device State
Not connected to the MQTT server, the
SW1 is switched off
Not connected to the MQTT server, the
SW1 is switched on
Press and hold(about 10 seconds) any
switch to factory reset the WS001-3
App configuring process(SoftAP) initiated
1/8
Advertisement
Table of Contents
Summary of Contents for MOKOSmart WS001-3
- Page 1 Solid blue and red Not connected to the MQTT server, the at the same time SW1 is switched on Blink blue once Press and hold(about 10 seconds) any switch to factory reset the WS001-3 Blink red rapidly App configuring process(SoftAP) initiated http://doc.mokotechnology.com/index.php?s=/page/5...
- Page 2 2019/11/2 ShowDoc LED State Device State Blink blue rapidly Connecting to the network and MQTT server Solid blue Connected to the MQTT server,the SW1 is switched on The SW1 is switched off SW2 LED Indication LED State Device State Solid blue The SW2 is switched on The SW2 is switched off SW3 LED Indication...
- Page 3 2019/11/2 ShowDoc Host: 45.77.124.18 （Please fill in your MQTT server address） Port: 1883 - TCP connect mode 8883 - SSL connect mode （Please fill in your MQTT server port） Username: admin （Please fill in your MQTT server username） Password: public （Please fill in your MQTT server password） http://doc.mokotechnology.com/index.php?s=/page/5...
- Page 4 2019/11/2 ShowDoc Step2: 1. Install your wall switch and connect to the power supply. 2. Press and hold （ about 10 seconds）any switch to factory reset the wall switch ，the SW1 blink blue once then blink red rapidly. 3. Click go to Select Device Type page then click Wall Switch go to Add Device page.
- Page 5 3. If the mobile phone prompt to change the network,please choose NO. Step5: 1. After connecting the “WS001-3-XXXX” hotspot , back to the MokoLife APP, it will prompt to enter Wi-Fi information. 2. Enter the available Wi-Fi information then click the Confirm button, MokoLife APP will send the Wi-Fi information to wall switch and then the wall switch will connect to the router and MQTT server，the SW1 blink blue rapidly.
- Page 6 2019/11/2 ShowDoc Step 6: 1. Connect successfully ,the SW1 Solid blue when the SW1 is swithed on. You can rename your wall switch and control the wall switch by MokoLife APP. Step7: 1. Click the ALL ON button to control all gang switch on. 2.
- Page 7 2019/11/2 ShowDoc Step8: 1. Click the Timer button to set the switch countdown timer. 2. When the switch in the countdown state,change the status of the switch ,the countdown will be cancelled immediately. http://doc.mokotechnology.com/index.php?s=/page/5...
- Page 8 2019/11/2 ShowDoc 本页面使用showdoc (https://www.showdoc.cc/)编写 http://doc.mokotechnology.com/index.php?s=/page/5...
